System And Components
360-1589 LINES GP-FUEL FILTERS/N LGK1-UP
Group No: 360-1589
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P0436 | 1 GASKET (FUEL PRIMING PUMP) | 1 | |
| 3S2093 | 2 STRAP-CABLE | 1 | |
| 1230783 | 3 VALVE GP-FLUID SAMPLING (FUEL) | 1 | |
| 1236948 | 4 PLUG | 1 | |
| 1375541 | 5 PUMP GP-FUEL PRIMING | 1 | |
| 0617539 | SEAL-O-RING | 1 | |
| 2293218 | VALVE AS | 2 | |
| 1396873 | 6 VALVE GP-FUEL BYPASS (FILTER) | 1 | |
| 2157350 | 7 BRACKET | 1 | |
| 2336742 | 8 VALVE GP-CHECK (FUEL) | 1 | |
| 2345013 | 9 SENSOR GP-TEMPERATURE | 1 | |
| 2379314 | 10 BASE AS | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 2490164 | 11 HOSE AS | 1 | |
| 2726666 | 12 TUBE AS | 1 | |
| 2726667 | 13 TUBE AS | 1 | |
| 2726668 | 14 HOSE AS | 1 | |
| 2746719 | 15 SENSOR GP-PRESSURE (FUEL) | 1 | |
| 2788844 | 16 PLUG AS-CONNECTOR | 1 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 3309732 | 17 ADAPTER AS | 1 | |
| 5P6944 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3609145 | 18 HARNESS AS-SENSOR | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 5 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 5 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 9 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 9 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 2304012 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 2370227 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 1325789 | 19 CLIP (LADDER) | 1 | |
| 1759079 | 20 ROD-LINK | 1 | |
| 1917805 | 21 ELBOW AS | 1 | |
| 0307947 | ADAPTER-ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2067337 | 22 TUBE AS | 1 | |
| 2287091 | 23 SEAL-O-RING | 1 | |
| 2385081 | 24 SEAL-O-RING | 2 | |
| 3072673 | 25 PLUG AS | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3139614 | 26 ADAPTER AS | 1 | |
| 2R6806 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3218654 | 27 ADAPTER AS | 1 | |
| 3P1932 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3218671 | 28 CONNECTOR AS | 1 | |
| 0308188 | CONNECTOR | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3535102 | 29 FITTING AS-ELBOW | 3 | |
| 0054362 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3535103 | 30 ADAPTER AS | 1 | |
| 0307942 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3535112 | 31 ADAPTER AS | 1 | |
| 9X0262 | ADAPTER | 1 | |
| 2147566 | SEAL-O-RING | 2 | |
| 3E4352 | 32 WASHER-HARD (8.8X20.5X2.5-MM THK) | 1 | |
| 5M2894 | 33 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5P0537 | 34 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 6V4248 | 35 BOLT (M10X1.5X25-MM) | 1 | |
| 6V5217 | 36 BOLT (M8X1.25X20-MM) | 1 | |
| 6V5218 | 37 BOLT (M8X1.25X35-MM) | 1 | |
| 6V5839 | 38 WASHER (11X21X2.5-MM THK) | 7 | |
| 6V5842 | 39 BOLT (M10X1.5X40-MM) | 3 | |
| 6V5843 | 40 BOLT (M10X1.5X45-MM) | 3 | |
| 7B9919 | 41 CLIP | 1 | |
| 7C6921 | 42 SPACER (11X20X22.8-MM THK) | 1 | |
| 7C8246 | 43 SPACER (10.5X20X24-MM THK) | 1 | |
| 7H7055 | 44 CLIP | 1 | |
| 7K4129 | 45 UNION-FLARED | 1 | |
| 7V6571 | 46 GROMMET | 1 | |
| 8T0640 | 47 BOLT (M6X1X30-MM) | 1 | |
| 8T1889 | 48 CLIP (SLOT) | 1 | |
| 8T1890 | 49 CLIP (TAB) | 1 | |
| 9J6189 | 50 CLIP | 1 | |
| 9M1974 | 51 WASHER-HARD (8.8X16X2-MM THK) | 1 |
