System And Components
360-1589 LINES GP-FUEL FILTERS/N LGK1-UP
Group No: 360-1589
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P0436 | 1 GASKET (FUEL PRIMING PUMP) | 1 | |
| 3S2093 | 2 STRAP-CABLE | 3 | |
| 1230783 | 3 VALVE GP-FLUID SAMPLING (FUEL) | 1 | |
| 3918662 | 4 PLUG AS | 1 | |
| 7L9061 | SEAL-O-RING | 1 | |
| 1236948 | PLUG | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 1375541 | 5 PUMP GP-FUEL PRIMING | 1 | |
| 0617539 | SEAL-O-RING | 1 | |
| 2293218 | VALVE AS | 2 | |
| 3826044 | 6 VALVE GP-CHECK | 1 | |
| 2157350 | 7 BRACKET | 1 | |
| 2336742 | 8 VALVE GP-CHECK (FUEL) | 1 | |
| 2345013 | 9 SENSOR GP-TEMPERATURE | 1 | |
| 2379314 | 10 BASE AS | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 2490164 | 11 HOSE AS | 1 | |
| 3256995 | 12 CLIP (TAB) | 1 | |
| 3882619 | 13 BRACKET AS | 1 | |
| 2726668 | 14 HOSE AS | 1 | |
| 2746719 | 15 SENSOR GP-PRESSURE (FUEL) | 1 | |
| 2788844 | 16 PLUG AS-CONNECTOR | 1 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 3309732 | 17 ADAPTER AS | 1 | |
| 5P6944 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3609145 | 18 HARNESS AS-SENSOR | 1 | |
| 1325789 | 19 CLIP (LADDER) | 1 | |
| 1759079 | 20 ROD-LINK | 1 | |
| 3866196 | 21 ELBOW AS | 1 | |
| 0307943 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3882621 | 22 HOSE & TUBE AS | 1 | |
| 3882622 | 23 HOSE & TUBE AS | 1 | |
| 2067337 | 24 TUBE AS | 1 | |
| 2Y5829 | 25 NUT (M10X1.5-THD) | 1 | |
| 3031506 | 26 ELBOW AS | 1 | |
| 4K6297 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3985596 | 27 PLUG AS | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3139614 | 28 ADAPTER AS | 1 | |
| 2R6806 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3218654 | 29 ADAPTER AS | 1 | |
| 3P1932 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3218671 | 30 CONNECTOR AS | 1 | |
| 0308188 | CONNECTOR | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3256994 | 31 CLIP (SLOT) | 1 | |
| 3535102 | 32 FITTING AS-ELBOW | 2 | |
| 0054362 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3535103 | 33 ADAPTER AS | 1 | |
| 0307942 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3535112 | 34 ADAPTER AS | 1 | |
| 9X0262 | ADAPTER | 1 | |
| 2147566 | SEAL-O-RING | 2 | |
| 3K1787 | 35 GROMMET | 1 | |
| 5M2894 | 36 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 9X8267 | 37 WASHER (6.6X12X2-MM THK) | 1 | |
| 5P8939 | 38 GROMMET | 1 | |
| 6V5218 | 39 BOLT (M8X1.25X35-MM) | 1 | |
| 6V5839 | 40 WASHER (11X21X2.5-MM THK) | 9 | |
| 6V5842 | 41 BOLT (M10X1.5X40-MM) | 3 | |
| 6V5843 | 42 BOLT (M10X1.5X45-MM) | 3 | |
| 6V6317 | 43 BOLT (M10X1.5X20-MM) | 1 | |
| 7C6921 | 44 SPACER (11X20X22.8-MM THK) | 1 | |
| 7C8246 | 45 SPACER (10.5X20X24-MM THK) | 1 | |
| 7K4129 | 46 UNION-FLARED | 1 | |
| 7V6571 | 47 GROMMET | 1 | |
| 8T0640 | 48 BOLT (M6X1X30-MM) | 1 | |
| 8T1889 | 49 CLIP (SLOT) | 2 | |
| 8T1890 | 50 CLIP (TAB) | 2 | |
| 9J6189 | 51 CLIP | 1 | |
| 9M1974 | 52 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 6V4248 | 53 BOLT (M10X1.5X25-MM) | 1 | |
| 8C5064 | 54 CONDUIT-FLEXIBLE (17.75-MM ID, SPLIT)(13-CM) |
