System And Components
490-0097 PUMP GP-FUEL PRIMINGS/N LGK1-UP
Group No: 490-0097
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2605864 | 1 SWITCH GP-TOGGLE (FUEL FILTER)(FUEL PRIMING PUMP) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 1124550 | SLEEVE (21-CM) | ||
| 2712180 | SWITCH AS-TOGGLE (ON, OFF) | 1 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6T3632 | LOCKWASHER | 1 | |
| 6T3633 | RING-LOCKING | 1 | |
| 1911782 | 2 SPACER (8.5X12.7X38.2-MM THK) | 1 | |
| 2066876 | 3 CAP-TUBE | 1 | |
| 2098441 | 4 HARNESS AS-PUMP (FUEL PRIMING) | 1 | |
| 2321374 | 5 BRACKET | 1 | |
| 2321376 | 6 SPACER (8.5X12.7X139.1-MM THK) | 2 | |
| 3006714 | 7 MOUNT | 8 | |
| 3985601 | 8 PLUG AS | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3603681 | PLUG (7/8-14-THD) | 1 | |
| 3779626 | 9 VALVE AS-DRAIN | 1 | |
| 1418275 | VALVE-DRAIN (FUEL) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 4420646 | 10 PUMP GP-FUEL PRIMING | 1 | |
| 3295459 | 11 ADAPTER AS | 1 | |
| 5P1404 | ADAPTER | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3E8005 | 12 BOLT (M8X1.25X160-MM) | 2 | |
| 5P7970 | 13 NUT (M8X1.25-THD) | 3 | |
| 8T0100 | 14 BOLT (M8X1.25X60-MM) | 1 | |
| 9N0869 | 15 WASHER-HARD (8.8X25.5X2-MM THK) | 6 | |
| 3053684 | 16 PLATE-IDENTIFICATION (FUEL PRIMING PUMP ON, OFF) | 1 |
