System And Components
125-9597 ALTERNATOR GP-CHARGINGS/N LGK1-UP
Group No: 125-9597
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1H3244 | 1 LOCKWASHER | 1 | |
| 6V8189 | 2 NUT (5/16-18-THD) | 1 | |
| 8T4205 | 3 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 3E5451 | 4 REGULATOR AS-VOLTAGE (12-VOLT)(ALTERNATOR) | 1 | |
| 9L6770 | 5 CAP-DUST | 1 | |
| 1872034 | 6 NUT-FLANGE (5/8-18-THD) | 1 | |
| 1262368 | 7 KIT-ALTERNATOR GUARD | 1 | |
| 8T4224 | 8 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 3F9556 | 9 LOCKWASHER | 1 | |
| 1374937 | 10 ROTOR AS-ALTERNATOR | 1 | |
| 3E5450 | 11 COVER | 1 | |
| 4B2043 | 12 NUT (8-32-THD) | 4 | |
| 9B7233 | 13 LOCKWASHER | 4 | |
| 3E5448 | 14 CONNECTOR | 1 | |
| 3E5446 | 15 CONNECTOR | 1 | |
| 3E5457 | 16 DIODE AS | 1 | |
| 2316126 | 17 RECTIFIER AS-ALTERNATOR | 1 | |
| 7N9023 | 18 SCREW AS (8-32X26.9-MM) | 3 | |
| 3E5460 | 19 HOLDER AS-BRUSH | 1 | |
| 3E5459 | 20 BRUSH AS-ALTERNATOR | 2 | |
| 3N3718 | 21 SCREW AS | 2 | |
| 3E5458 | 22 CAPACITOR AS-ALTERNATOR | 1 | |
| 8T9367 | 23 BOLT (1/4-20X2-IN) | 1 | |
| 3E5454 | 24 FAN-ALTERNATOR (11-BLADE) | 1 | |
| 3E5455 | 25 HOUSING | 1 | |
| 5P7807 | 26 BALL BEARING | 1 | |
| 3E5447 | 27 PLATE | 1 | |
| 0309612 | 28 SCREW-FORMING (10-24X0.5-IN) | 3 | |
| 1374938 | 29 STATOR AS-ALTERNATOR | 1 | |
| 1321230 | 30 KIT-ALTERNATOR TERMINAL (RELAY) | 1 | |
| 1321224 | 31 FRAME AS-ALTERNATOR | 1 | |
| 5P6920 | 32 BEARING-ROLLER | 1 | |
| 3E5462 | 33 KIT-ALTERNATOR TERMINAL (BATTERY) | 1 |
