System And Components
266-7227 ALTERNATOR GP-CHARGINGS/N LGK1-14748
Group No: 266-7227
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4205 | 1 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 1H3244 | 2 LOCKWASHER | 1 | |
| 6V8187 | 3 NUT (1/4-28-THD) | 1 | |
| 2923815 | 4 KIT-TERMINAL | 2 | |
| 9L6770 | 5 CAP-DUST | 1 | |
| 5P3418 | 6 BEARING-ROLLER | 1 | |
| 5P3419 | 7 RACE-BEARING INNER | 1 | |
| 2918247 | 8 RECTIFIER AS | 1 | |
| 2022708 | 9 DIODE AS | 1 | |
| 3T6354 | 10 REGULATOR AS-VOLTAGE (24-VOLT)(ALTERNATOR) | 1 | |
| 2918253 | 11 CAPACITOR AS | 1 | |
| 2029897 | 12 BEARING-SPECIAL BALL | 1 | |
| 1006531 | 13 FAN-ALTERNATOR (11-BLADE) | 1 | |
| 1872034 | 14 NUT-FLANGE (5/8-18-THD) | 1 | |
| 2918274 | 15 PLATE | 1 | |
| 2918271 | 16 HOUSING AS | 1 | |
| 2022700 | 17 FRAME | 1 | |
| 2918263 | 18 STATOR AS | 1 | |
| 6N1945 | 19 COIL AS-FIELD | 1 | |
| 9S2390 | 20 RETAINER | 1 | |
| 9S2302 | 21 ROTOR AS | 1 | |
| 4B2047 | 22 NUT (10-24-THD) | 1 | |
| 8T0328 | 23 WASHER-HARD (5.5X10X1-MM THK) | 1 | |
| 8F1434 | 24 LOCKWASHER | 1 | |
| 2022784 | 25 KIT-ALTERNATOR TERMINAL (OUTPUT) | 1 | |
| 2022785 | 26 KIT-ALTERNATOR TERMINAL (RELAY) | 1 | |
| 2022786 | 27 KIT-ALTERNATOR TERMINAL (INDICATOR LIGHT) | 1 | |
| 2022787 | KIT-HARDWARE (ALTERNATOR AIR) | 1 |
