System And Components
331-5717 ALTERNATOR GP-CHARGINGS/N LGK14749-UP
Group No: 331-5717
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4205 | 1 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 1H3244 | 2 LOCKWASHER | 1 | |
| 6V8187 | 3 NUT (1/4-28-THD) | 2 | |
| 9L6770 | 4 CAP-DUST | 1 | |
| 2316133 | 5 KIT-BEARING (ALTERNATOR) | 1 | |
| 5P3419 | RACE-BEARING INNER | 1 | |
| 2299407 | BEARING AS | 1 | |
| 3081362 | 6 RECTIFIER AS | 1 | |
| 2022708 | 7 DIODE AS (ALTERNATOR) | 1 | |
| 3T6354 | 8 REGULATOR AS-VOLTAGE (24-VOLT)(ALTERNATOR) | 1 | |
| 2029897 | 9 BEARING-SPECIAL BALL | 1 | |
| 1006531 | 10 FAN-ALTERNATOR (11-BLADE) | 1 | |
| 1872034 | 11 NUT-FLANGE (5/8-18-THD) | 1 | |
| 2022783 | 12 PLATE | 1 | |
| 2923815 | 13 KIT-TERMINAL | 1 | |
| 2022700 | 14 FRAME (ALTERNATOR) | 1 | |
| 3081365 | 15 STATOR AS (ALTERNATOR) | 1 | |
| 3081366 | 16 COIL AS (ALTERNATOR) | 1 | |
| 9S2390 | 17 RETAINER | 1 | |
| 2991761 | 18 ROTOR AS | 1 | |
| 4B2047 | 19 NUT (10-24-THD) | 1 | |
| 8T0328 | 20 WASHER-HARD (5.5X10X1-MM THK) | 1 | |
| 8F1434 | 21 LOCKWASHER | 1 | |
| 2022784 | 22 KIT-ALTERNATOR TERMINAL | 1 | |
| 2022785 | 23 KIT-ALTERNATOR TERMINAL | 1 | |
| 2022787 | 24 KIT-HARDWARE (ALTERNATOR) | 1 | |
| 3288410 | 25 KIT-TERMINAL | 1 |
