System And Components
4N-3986 ALTERNATOR GP-CHARGINGS/N LGK1-14748
Group No: 4N-3986
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N1876 | 1 HOUSING AS (RECTIFIER) | 1 | |
| 9S2396 | 2 BUSHING-TERMINAL | 1 | |
| 9N0943 | 3 PLUG-BEARING WELL | 1 | |
| 5P3418 | 4 BEARING-ROLLER | 1 | |
| 6N1968 | 5 STATOR AS | 1 | |
| 2L8075 | TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 3 | |
| 9N0939 | GROMMET | 1 | |
| 9N0942 | 6 PLATE-COVER | 1 | |
| 2P5616 | 7 FRAME-DRIVE END | 1 | |
| 9S2390 | 8 RETAINER | 1 | |
| 9N0937 | 9 RECTIFIER AS | 1 | |
| 9S2302 | 10 ROTOR AS | 1 | |
| 5P7807 | 11 BALL BEARING | 1 | |
| 1006531 | 12 FAN-ALTERNATOR (11-BLADE) | 1 | |
| 5P3419 | 13 RACE-BEARING INNER | 1 | |
| 7F7621 | 14 WASHER (0.635X1.25X0.09-IN THK) | 1 | |
| 2K4821 | 15 LOCKNUT (5/8-18-THD) | 1 | |
| 6N1945 | 16 COIL AS-FIELD | 1 | |
| 9X2500 | 17 SCREW-HEX FLANGE (10-24X38.1-MM) | 4 | |
| 9N3388 | 18 BOLT (10-24X0.75-IN) | 5 | |
| 1006532 | 19 COLLAR-ALTERNATOR | 1 | |
| 9S2009 | 20 BOLT-FLANGE HEAD (10-24X3.625-IN) | 4 | |
| 6N1944 | 21 DIODE AS | 1 | |
| 6N1870 | 22 SCREW AS (8-32X34-MM) | 2 | |
| 8T0328 | 23 WASHER-HARD (5.5X10X1-MM THK) | 2 | |
| 9S2544 | 24 SCREW-HEX HEAD (8-32X11.13-MM) | 7 | |
| 9B7233 | 25 LOCKWASHER | 11 | |
| 4B2043 | 26 NUT (8-32-THD) | 4 | |
| 6V8187 | 27 NUT (1/4-28-THD) | 2 | |
| 1H3244 | 28 LOCKWASHER | 2 | |
| 6N1925 | 29 BRACKET | 1 | |
| 6N1946 | 30 CAPACITOR AS | 1 | |
| 6N1872 | 31 SCREW AS (8-32X1.25-IN) | 3 | |
| 3T6354 | 32 REGULATOR AS-VOLTAGE (24-VOLT)(ALTERNATOR) | 1 | |
| 6N1873 | 33 LEAD AS | 1 | |
| 2L8075 | 34 TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 3 | |
| 8T4205 | 35 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 6N1871 | 36 LEAD AS | 1 | |
| 8M6701 | 37 WASHER (0.281X0.5X0.032-IN THK) | 3 | |
| 6N1856 | 38 BUSHING-TERMINAL | 4 | |
| 6N1875 | KIT-OUTPUT TERMINAL (ALTERNATOR) | 1 | |
| 1053762 | KIT-ALTERNATOR TERMINAL | 1 |
