System And Components
5N-5692 ALTERNATOR GP-CHARGINGS/N LGK1-UP
Group No: 5N-5692
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P6920 | 1 BEARING-ROLLER | 1 | |
| 7N7806 | 2 COIL AS-FIELD | 1 | |
| 9G5578 | 3 STATOR AS (24-VOLT) | 1 | |
| 7N7795 | 4 COLLAR | 1 | |
| 7N7810 | 5 FRAME AS-DRIVE END | 1 | |
| 6V2202 | 6 BALL BEARING | 1 | |
| 9L2140 | 7 PLATE | 1 | |
| 7X3353 | 8 SCREW-HEX HEAD (10X24X19.05-MM) | 4 | |
| 7N7800 | 9 ROTOR AS | 1 | |
| 1872034 | 10 NUT-FLANGE (5/8-18-THD) | 1 | |
| 0309612 | 12 SCREW-FORMING (10-24X0.5-IN) | 5 | |
| 9L2139 | 13 WASHER-FELT (1.31X1.68X0.125-IN THK) | 1 | |
| 3E5454 | 14 FAN-ALTERNATOR (11-BLADE) | 1 | |
| 9S2437 | 15 SCREW-TAPPING (10-24X19.05-MM) | 3 | |
| 9L2137 | 16 RETAINER AS | 1 | |
| 8F1434 | 17 LOCKWASHER | 4 | |
| 7N9024 | 18 BOLT (10-24X2.5-IN) | 4 | |
| 7N7805 | 19 HOUSING | 1 | |
| 7N7809 | 20 PLATE | 1 | |
| 8T4205 | 21 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 9B7233 | 22 LOCKWASHER | 6 | |
| 9L6770 | 23 CAP-DUST | 1 | |
| 6N1872 | 25 SCREW AS (8-32X1.25-IN) | 2 | |
| 7N9023 | 26 SCREW AS (8-32X26.9-MM) | 2 | |
| 3T6354 | 27 REGULATOR AS-VOLTAGE (24-VOLT)(ALTERNATOR AIR) | 1 | |
| 6V8377 | 28 NUT (8-32-THD) | 4 | |
| 7N7811 | 29 CONNECTOR | 1 | |
| 8T0328 | 30 WASHER-HARD (5.5X10X1-MM THK) | 6 | |
| 1129119 | 31 DIODE AS-ALTERNATOR | 1 | |
| 7N9021 | 32 SCREW AS (8-32X1.34-IN) | 1 | |
| 7N7796 | 33 BUSHING-TERMINAL | 1 | |
| 7N7802 | 34 CAPACITOR AS | 1 | |
| 7N7798 | 35 CONNECTOR | 1 | |
| 7N7801 | 36 CONNECTOR | 1 | |
| 9S2544 | 37 SCREW-HEX HEAD (8-32X11.13-MM) | 2 | |
| 1H3244 | 38 LOCKWASHER | 1 | |
| 6V8187 | 39 NUT (1/4-28-THD) | 1 | |
| 2064202 | 40 RECTIFIER AS | 1 | |
| 7N7807 | KIT-OUTPUT TERMINAL (ALTERNATOR) | 1 | |
| 7N7808 | KIT-RELAY TERMINAL (ALTERNATOR) | 1 |
