System And Components
288-7330 CONTROL GP-DRIVE AXLE -8-SPEED, TRANSFER GEAR-4WDS/N SMS1-UP
Group No: 288-7330
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 16 | |
| 1918304 | 2 SENSOR GP-SPEED (TRANSMISSION OUTPUT) | 2 | |
| 2250300 | 3 VALVE GP-SOLENOID (TRANSFER GEAR) | 6 | |
| 2862537 | 4 HARNESS AS-TRANSMISSION (4-WHEEL DRIVE) | 1 | |
| 7G7917 | PLUG-SEAL | 3 | |
| 8N1525 | PLUG AS-CONNECTOR (20-PIN) | 1 | |
| 8N1535 | BELL AS-END | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 21 | |
| 8T8737 | PLUG-SEAL | 3 | |
| 9X6772 | STRAP-CABLE | 1 | |
| 9X6857 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 17 | |
| 1148843 | SLEEVE-PLASTIC (220-CM) | ||
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(5-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(15-CM) | ||
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 8 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 3 | |
| 0965969 | 5 BOLT-SOCKET HEAD (M5X0.8X25-MM) | 6 | |
| 1013625 | 6 CLIP (LADDER) | 1 | |
| 1171385 | 7 SEAL-O-RING | 2 | |
| 1305300 | 8 CLIP | 5 | |
| 1325789 | 9 CLIP (LADDER) | 5 | |
| 2148970 | 10 SENSOR GP-POSITION (TRANSMISSION) | 3 | |
| 2040728 | SEAL-O-RING | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 1519274 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 4P7581 | 11 CLIP (LADDER) | 6 | |
| 8T4200 | 12 BOLT (M8X1.25X16-MM) | 2 | |
| 8T0328 | 13 WASHER-HARD (5.5X10X1-MM THK) | 6 | |
| 8T1158 | 14 BOLT-SOCKET HEAD (M8X1.25X20-MM) | 6 | |
| 8T4224 | 15 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 3085138 | 16 HARNESS AS-TRANSMISSION (FILTER) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 1148843 | SLEEVE-PLASTIC (60-CM) | ||
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 |
