System And Components
207-1549 STARTING MOTOR GP-ELECTRICS/N LGK1-UP
Group No: 207-1549
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3T3434 | 1 PLUG | 6 | |
| 7T3279 | 2 HOUSING AS | 1 | |
| 8T8566 | 3 TERMINAL AS | 1 | |
| 6V8188 | 4 NUT (1/2-13-THD) | 4 | |
| 7X0562 | 5 WASHER-HARD (13.5X19X0.8-MM THK) | 4 | |
| 3T3422 | 6 WIRE AS | 1 | |
| 7T3278 | 7 HOLDER AS-BRUSH (STARTING MOTOR) | 1 | |
| 7T3277 | 8 COIL AS-FIELD | 1 | |
| 7T3454 | 9 INSULATOR | 1 | |
| 7T3271 | 10 CONNECTOR | 1 | |
| 7T3451 | 11 KIT-INSULATOR (STARTING MOTOR) | 1 | |
| 8T8569 | 12 INSULATOR-TERMINAL | 1 | |
| 5S7349 | 13 BOLT (1/4-20X0.5-IN) | 4 | |
| 8T4205 | 14 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 8H1141 | 15 SHOE-POLE | 4 | |
| 3F0379 | 16 SCREW-POLE SHOE (3/8-24-THD) | 8 | |
| 7T3276 | 17 ARMATURE AS (24-VOLT) | 1 | |
| 3E7775 | 18 HOUSING AS | 1 | |
| 4M1831 | 19 PLUG-LEVER HOUSING | 1 | |
| 7L2894 | 20 GASKET | 1 | |
| 0369823 | 21 BOLT (1/4-28X1-IN) | 5 | |
| 6N3826 | 22 DRIVE AS-MOTOR | 1 | |
| 7T3974 | 23 HOUSING AS-DRIVE | 1 | |
| 7X3373 | 24 BOLT (5/16-18X0.88-IN) | 6 | |
| 1938570 | 25 SOLENOID AS-STARTING MOTOR (24-VOLT) | 1 | |
| 6V8378 | 26 NUT (10-32-THD) | 2 | |
| 8F1434 | 27 LOCKWASHER | 2 | |
| 8T0328 | 28 WASHER-HARD (5.5X10X1-MM THK) | 2 | |
| 8C3655 | KIT-BRUSH (STARTING MOTOR) | 1 | |
| 7T3267 | KIT-BUSHING (STARTING MOTOR) | 1 | |
| 7T3268 | KIT-LEVER (STARTING MOTOR) | 1 | |
| 8T9884 | KIT-INSULATOR (STARTING MOTOR) | 1 |
