System And Components
352-9765 STARTING MOTOR GP-ELECTRICS/N LGK1-UP
Group No: 352-9765
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9H3757 | 1 WASHER (0.516X1X0.094-IN THK) | 2 | |
| 7M0327 | 2 WASHER-THRUST (17.4X25.4X1.6-MM THK) | 1 | |
| 3T3418 | 3 FRAME AS-END | 1 | |
| 3T3423 | CUP | 1 | |
| 3T3424 | PLUG-FELT | 1 | |
| 9G4101 | BUSHING-END | 1 | |
| 1T0808 | 4 WASHER (0.516X0.812X0.09-IN THK) | 2 | |
| 3T3422 | 5 WIRE AS (STARTING MOTOR) | 1 | |
| 2J8163 | 6 SEAL-O-RING | 2 | |
| 7X3373 | 7 BOLT (5/16-18X0.88-IN) | 1 | |
| 3T3434 | 8 PLUG | 6 | |
| 5J5314 | 9 BOLT (5/16-18X1.5-IN) | 5 | |
| 3L3380 | 10 BUSHING-TERMINAL | 1 | |
| 8C3089 | 11 SEAL-O-RING | 1 | |
| 4M1853 | 12 LEVER AS-SHIFT | 1 | |
| 5M3034 | 13 LOCKNUT (5/16-24-THD) | 1 | |
| 7L2894 | 14 GASKET | 4 | |
| 4M1831 | 15 PLUG-LEVER HOUSING | 4 | |
| 4M1854 | 16 SHAFT-LEVER | 1 | |
| 1H1023 | 17 SEAL-O-RING | 1 | |
| 2D6392 | 18 SEAL-O-RING | 1 | |
| 7T3974 | 19 HOUSING AS-DRIVE | 1 | |
| 6N3826 | 20 DRIVE AS-MOTOR | 1 | |
| 2H3429 | 21 RING-RETAINING | 1 | |
| 6V1322 | 22 BOLT (1/4-20X0.375-IN) | 4 | |
| 8T4205 | 23 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 0S1597 | 24 BOLT (1/4-28X1-IN) | 13 | |
| 3R8797 | 25 SCREW & WASHER AS (3/8-24X0.72-IN) | 12 | |
| 3N3763 | 26 KIT-TERMINAL (STARTING MOTOR) | 1 | |
| 3625020 | 27 SOLENOID AS-STARTING MOTOR (12-VOLT) | 1 | |
| 3R8801 | 28 CLAMP | 1 | |
| 8F1434 | 29 LOCKWASHER | 2 | |
| 6V8188 | 30 NUT (1/2-13-THD) | 6 | |
| 7X0562 | 31 WASHER-HARD (13.5X19X0.8-MM THK) | 6 | |
| 4B2049 | 32 NUT (10-32-THD) | 6 | |
| 8T0328 | 33 WASHER-HARD (5.5X10X1-MM THK) | 10 | |
| 3E7771 | 34 HOUSING AS (STARTING MOTOR) | 1 | |
| 9G4101 | 35 BUSHING-END | 1 | |
| 3T3424 | 36 PLUG-FELT | 3 | |
| 3T3423 | 37 CUP | 3 | |
| 1M9968 | 38 BUSHING | 1 | |
| 2F6678 | 39 SEAL-LIP TYPE | 1 | |
| 4L2729 | 40 WASHER (0.844X1.9X0.188-IN THK) | 1 | |
| 4M1896 | 41 BUSHING-TERMINAL | 1 | |
| 0454065 | 42 SCREW-MACHINE (10-32X0.75-IN) | 4 | |
| 1256535 | 44 COVER-STARTING MOTOR | 1 |
