System And Components
219-7462 WIRING GP-ELECTRONIC CONTROLS/N LGK1-UP
Group No: 219-7462
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 15 | |
| 9X2097 | 3 STUD (M8X1.25-THD) | 1 | |
| 2062423 | 4 SADDLE-MOUNTING | 1 | |
| 2197461 | 5 HARNESS AS-CONTROL (ELECTRONIC CONTROL MODULE) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 2 | |
| 3S2093 | STRAP-CABLE | 2 | |
| 8T8737 | PLUG-SEAL | 81 | |
| 1051797 | MOUNT | 1 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552265 | KIT-CONNECTING PLUG (8-PIN) | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 5 | |
| 1945226 | TERMINAL AS (16-GA) | 62 | |
| 1945227 | TERMINAL AS (14-GA) | 62 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 6 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 6 | |
| 2116807 | COVER-CONNECTOR | 1 | |
| 2645732 | PLUG AS-CONNECTOR (120-PIN) | 1 | |
| 2887324 | SEAL-CONNECTOR | 1 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(5-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(15-CM) | ||
| 3035952 | 6 STRAP-CABLE | 1 | |
| 1325789 | 7 CLIP (LADDER) | 2 | |
| 1566175 | 8 CLIP (LADDER) | 2 | |
| 2Y5829 | 10 NUT (M10X1.5-THD) | 1 | |
| 4P7581 | 11 CLIP (LADDER) | 3 | |
| 5P9085 | 12 CLIP (LOOP) | 1 | |
| 6V3918 | 13 BOLT (M8X1.25X50-MM) | 1 | |
| 6V5839 | 14 WASHER (11X21X2.5-MM THK) | 5 | |
| 6V8212 | 15 BOLT (M10X1.5X16-MM) | 4 | |
| 6V8836 | 16 BOLT (M6X1X14-MM) | 2 | |
| 9M1974 | 19 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9X8267 | 20 WASHER (6.6X12X2-MM THK) | 2 |
