Assembly
100%

357-0524 WIRING GP-ELECTRONIC CONTROLS/N LGK1-UP

Group No: 357-0524
Part NumberPart NameQty
3S20931 STRAP-CABLE12
4P74282 CLIP (LADDER)1
9X20973 STUD (M8X1.25-THD)1
38526644 HARNESS AS-ENGINE (WIRING)1
13257895 CLIP (LADDER)3
15661756 CLIP (LADDER)2
2Y58297 NUT (M10X1.5-THD)1
4P75818 CLIP (LADDER)1
6V39189 BOLT (M8X1.25X50-MM)1
6V583910 WASHER (11X21X2.5-MM THK)5
6V821211 BOLT (M10X1.5X16-MM)4
6V883612 BOLT (M6X1X14-MM)2
9X826713 WASHER (6.6X12X2-MM THK)2
9M197414 WASHER-HARD (8.8X16X2-MM THK)2
4P813415 CLIP (LADDER)1
3E435316 WASHER-HARD (11X25X3-MM THK)1
5P824517 WASHER-HARD (13.5X25.5X3-MM THK)1
6V424918 BOLT (M10X1.5X50-MM)1
6V817719 BOLT (M12X1.75X16-MM)1
8M277020 CLIP (LOOP)1
9G710121 SPACER (11X20X30-MM THK)1
206134522 STRAP-CABLE2
288102323 BRACKET-SUPPORT1
352397024 CLIP (LADDER)1
