System And Components
297-6995 PUMP GP-HYDRAULICS/N LGK1-UP
Group No: 297-6995
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2052909 | 1 SHAFT-PUMP | 1 | |
| 8C3110 | 2 RING-RETAINING | 1 | |
| 1660344 | 3 SEAL-SHAFT | 2 | |
| 9S8002 | 4 PLUG (7/16-20-THD) | 1 | |
| 3J7354 | 5 SEAL-O-RING | 1 | |
| 1886303 | 6 SPRING | 1 | |
| 2747452 | 7 LINK-CONTROL | 1 | |
| 1886299 | 8 PISTON | 1 | |
| 3107792 | 9 PLUG | 1 | |
| 8T7525 | 10 SEAL-O-RING | 1 | |
| 9X8979 | 11 DOWEL | 1 | |
| 2807870 | 12 GASKET | 1 | |
| 1683504 | 13 SEAL | 1 | |
| 1204394 | 14 PLUG-BREAK OFF | 1 | |
| 0950670 | 15 BOLT (M12X1.75X45-MM) | 4 | |
| 2855240 | 16 VALVE GP-PUMP CONTROL (PRESSURE, FLOW COMPENSATOR)(PRESSURE, FLOW COMPENSATOR) | 1 | |
| 8T8442 | 17 BOLT-SOCKET HEAD (M6X1X30-MM) | 4 | |
| 1279485 | 18 SEAL-O-RING | 1 | |
| 2426903 | 19 SHIM (3-MM THK) | 1 | |
| 2735073 | 20 ROTATING GP-PUMP (BRAKE, HYDRAULIC FAN) | 1 | |
| 3128769 | 21 SWASHPLATE | 1 | |
| 1886320 | 22 BEARING | 1 | |
| 1850263 | 23 BEARING | 1 | |
| 2038609 | 24 CUP-BEARING | 1 | |
| 1053035 | 25 CONE-BEARING | 1 |
