243-3029 PANEL GP-INSTRUMENTS/N LGK1-UP

Group No: 243-3029

Part Number	Part Name	Qty
2N0816	1 PANEL-INSTRUMENT	1
2N5848	2 BASE AS	1
2W3681	3 INDICATOR AS (ENGINE OIL PRESSURE)	1
3S2093	4 STRAP-CABLE	3
6N3171	5 COVER-PANEL	1
7W2731	6 RETAINER	3
8F0244	7 GROMMET	3
1111374	8 BRACKET	3
1480202	9 HOSE AS	1
1637833	10 INDICATOR AS (FUEL PRESSURE)	1
3574613	11 ADAPTER AS	1
2353612	ADAPTER	1
6V6609	SEAL-O-RING	1
2433030	12 BRACKET AS	1
2826839	13 HOSE AS	1
3474439	14 TEE AS	1
6M6853	TEE-O-RING	1
2147568	SEAL-O-RING	1
0307961	15 ELBOW	1
1325789	16 CLIP (LADDER)	2
2005233	17 GAUGE GP-COOLANT TEMPERATURE	1
4B2049	17A NUT (10-32-THD)	2
8F1434	17B LOCKWASHER	2
3L2875	18 CLIP	3
3S1099	19 ELBOW-FLARED	1
4B2041	20 NUT (6-32-THD)	2
5C2890	21 NUT (M6X1-THD)	3
5C7261	22 NUT (M8X1.25-THD)	2
5D9231	23 CONNECTOR	1
9M1974	24 WASHER-HARD (8.8X16X2-MM THK)	2
5S7348	25 SCREW-MACHINE (6-32X0.375-IN)	2
8T1890	26 CLIP (TAB)	1
6V3507	27 SEAL-RECTANGULAR	3
8T1889	28 CLIP (SLOT)	1
8T7934	29 WASHER-HARD (11X21X5-MM THK)	1
3498383	30 ADAPTER AS	1
7J4026	ELBOW	1
2147568	SEAL-O-RING	1
8T4136	31 BOLT (M10X1.5X25-MM)	1
8T4121	32 WASHER-HARD (11X21X2.5-MM THK)	8
8T4133	33 NUT (M10X1.5-THD)	3
8T4137	34 BOLT (M10X1.5X20-MM)	8
6V5217	35 BOLT (M8X1.25X20-MM)	2
8T4224	36 WASHER-HARD (8.8X16X2-MM THK)	2
8T4971	37 BOLT (M6X1X30-MM)	3
9B1117	38 LOCKWASHER	2
3072673	39 PLUG AS	1
9S8005	PLUG (3/4-16-THD)	1
2385080	SEAL-O-RING	1
1833407	40 PLUG AS	1
9S8004	PLUG (9/16-18-THD)	1
2147568	SEAL-O-RING	1
9X8256	41 WASHER (6.6X12X2-MM THK)	6
6V0826	42 GROMMET	1
