System And Components
540-4510 INSTALLATION AR-ENGINEPART OF 388-2105, 568-1010 ENGINE AR-COMPLETE
Group No: 540-4510
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4W9160 | 1 CLAMP-V BAND | 3 | |
| 7X0447 | 2 NUT (7/16-14-THD) | 12 | |
| 8C6354 | 3 CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 8T5360 | 4 WASHER (12X22.5X2.5-MM THK) | 12 | |
| 8T8729 | 5 PIN-CONNECTOR (16-GA TO 20-GA) | 9 | |
| 8T8737 | 6 PLUG-SEAL | 70 | |
| 9W1951 | 7 RECEPTACLE AS-CONNECTOR (9-PIN) | 1 | |
| 9X3402 | 8 SOCKET-CONNECTOR (16-GA TO 18-GA) | 20 | |
| 1607689 | 9 PLUG AS-CONNECTOR (70-PIN) | 1 | |
| 1599322 | SEAL-O-RING | 1 | |
| 1951068 | 10 BASE AS-FUEL FILTER | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 1983899 | 11 SCREW-BUTTON HEAD (M8X1.25X20-MM) | 12 | |
| 2661467 | 12 SENSOR GP-POSITION (ROTARY)(500-HZ PWM BUFFER) | 1 | |
| 2918380 | 13 COVER GP-ACCESS | 1 | |
| 4395113 | 14 FILTER GP-WATER SEP & FUEL | 1 |
