Assembly
100%

353-7004 GUARD GP-BELTS/N PDM1-UP

Group No: 353-7004
Part NumberPart NameQty
35370051 BRACKET AS1
6V7744LOCKNUT (M10X1.5-THD)4
8T3490NUT-WELD (M10X1.5-THD)4
2089295BOLT-FLANGE HEAD (M10X1.5X40-MM)4
35370062 BRACKET AS1
6V7744LOCKNUT (M10X1.5-THD)2
8T3490NUT-WELD (M10X1.5-THD)2
2089295BOLT-FLANGE HEAD (M10X1.5X40-MM)2
35370073 BRACKET AS1
6V7744LOCKNUT (M10X1.5-THD)4
8T3490NUT-WELD (M10X1.5-THD)4
3447932BOLT-FLANGE HEAD (M10X1.5X35-MM)4
35370084 GUARD AS (RH)1
35370095 GUARD AS (LH)1
6V7744LOCKNUT (M10X1.5-THD)2
3447932BOLT-FLANGE HEAD (M10X1.5X35-MM)2
35370106 GUARD AS1
5P10767 WASHER-HARD (13.5X30X4-MM THK)4
8T25028 BOLT (3/8-16X1.125-IN)2
8T48969 WASHER-HARD (10.2X18.5X2.5-MM THK)2
5C656510 BOLT (1/2-13X1.125-IN)4
