System And Components
269-2509 HOUSING GP-FRONTS/N JRE1-1597
Group No: 269-2509
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1209243 | 1 STUD-SPECIAL (BRAKE) | 2 | |
| 1261757 | 2 WASHER (10.85X19.3X1.27-MM THK)(MARKED Y) | 9 | |
| 1295427 | 3 WASHER-SPECIAL (SEALING) | 2 | |
| 1295428 | 4 STUD (BRAKE)(MARKED Y) | 12 | |
| 1559524 | 5 SEAL-INTEGRAL | 1 | |
| 1669144 | 6 GASKET | 1 | |
| 1751483 | 7 HOUSING AS-FRONT | 1 | |
| 3E8044 | 7A STUD (1/2-13X2.95-IN) | 1 | |
| 2230533 | 8 PLATE | 1 | |
| 0L2070 | 9 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S1588 | 10 BOLT (3/8-16X1.25-IN)(MARKED X) | 6 | |
| 0T0055 | 11 BOLT (3/8-16X4.25-IN) | 1 | |
| 5M2894 | 12 WASHER-HARD (10.2X18.5X2.5-MM THK)(MARKED X) | 17 | |
| 5P4255 | 13 BOLT-LOCKING (3/8-16X1-IN)(MARKED Z) | 8 | |
| 9S8752 | 14 NUT-FULL (3/8-16-THD)(MARKED Z) | 1 |
