System And Components
383-2299 LINES GP-AIR COMPRESSORS/N PDM1-UP
Group No: 383-2299
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6L4724 | 1 CLIP-TUBE | 1 | |
| 2733770 | 2 BRACKET | 1 | |
| 3668006 | 3 HOSE AS | 1 | |
| 0L1131 | 4 CLIP | 1 | |
| 1195155 | 5 SEAL-O-RING | 1 | |
| 1497738 | 6 CLIP (LOOP) | 2 | |
| 2287093 | 7 SEAL-O-RING | 2 | |
| 6V1903 | 8 SEAL-O-RING | 1 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4133 | 10 NUT (M10X1.5-THD) | 3 | |
| 8T4195 | 11 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4196 | 12 BOLT (M10X1.5X35-MM) | 1 | |
| 8T6453 | 13 CONNECTOR | 1 | |
| 8T8986 | 14 ELBOW | 1 | |
| 9R6307 | 15 SPACER (11X28X12-MM THK) | 1 |
