System And Components
311-1436 LINES GP-TURBOCHARGERS/N JRE1-UP; MCW1-UP
Group No: 311-1436
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N7878 | 1 PLATE-COVER | 2 | |
| 9M7540 | 2 CLAMP-TUBE | 2 | |
| 2413283 | 3 GASKET | 4 | |
| 3111437 | 4 TUBE AS | 1 | |
| 3111438 | 5 TUBE AS | 1 | |
| 3664665 | 6 CONNECTOR AS | 1 | |
| 6V5063 | SEAL-O-RING | 1 | |
| 0308189 | CONNECTOR | 1 | |
| 0S1588 | 7 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1594 | 8 BOLT (3/8-16X1-IN) | 8 | |
| 1B3057 | 9 CLIP | 1 | |
| 5M2894 | 10 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 5S7382 | 12 BOLT (3/8-16X1.375-IN) | 1 | |
| 3535130 | 13 ADAPTER AS | 1 | |
| 8M0505 | ADAPTER | 1 | |
| 6V6609 | 13A SEAL-O-RING | 1 | |
| 8M0547 | 14 ELBOW-FLARED (SWIVEL) | 1 | |
| 9M6527 | 15 WASHER-HARD (10.2X25.5X5-MM THK) | 1 | |
| 9S8752 | 16 NUT-FULL (3/8-16-THD) | 1 | |
| 5P1075 | 17 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 6V8801 | 18 NUT (3/8-16-THD) | 1 | |
| 7X0575 | 19 WASHER-HARD (10.2X22.5X5-MM THK) | 1 |
