System And Components
185-1676 SHUTOFF GP-AIR -12-VOLTS/N JRE1-UP; MCW1-UP
Group No: 185-1676
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1197556 | 1 ELBOW | 1 | |
| 5N5664 | 2 BRACKET AS | 1 | |
| 4N3889 | 3 SOLENOID-SHUTOFF (12-VOLT)(AIR INLET) | 1 | |
| 1W9070 | 4 DIODE AS | 1 | |
| 6D2928 | 5 BOLT (1/4-20X1.125-IN) | 2 | |
| 8T4205 | 6 WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 5N5662 | 7 LATCH | 1 | |
| 6V8185 | 8 NUT (1/4-20-THD) | 5 | |
| 1199457 | 9 ROD-HANDLE | 1 | |
| 5H1190 | 10 SEAL-LIP TYPE | 1 | |
| 5N3852 | 11 BEARING | 2 | |
| 4N2883 | 12 SHAFT-SHUTOFF | 1 | |
| 2L3605 | 12A PIN-SPRING | 1 | |
| 5N2829 | 12B BUSHING-TERMINAL | 1 | |
| 4P8021 | 13 VALVE AS (AIR SHUTOFF) | 1 | |
| 1C0569 | 14 BOLT (5/16-18X0.5-IN) | 2 | |
| 9S5282 | 15 WASHER-HARD (8.8X14.5X2-MM THK) | 2 | |
| 3N7848 | 16 SPRING | 1 | |
| 5N1703 | 17 SPACER (6.8X21X9.52-MM THK) | 1 | |
| 1082858 | 18 SPRING | 1 | |
| 0S1594 | 19 BOLT (3/8-16X1-IN) | 2 | |
| 5M2894 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5N5129 | 21 SHAFT | 1 | |
| 5N5131 | 22 BLOCK AS | 1 | |
| 5H5744 | 22A BUSHING-TERMINAL | 1 | |
| 8T6765 | 23 PLUG-PIPE (1/4-18-THD) | 1 | |
| 0S1588 | 24 BOLT (3/8-16X1.25-IN) | 4 | |
| 1013125 | 25 GASKET (AIR INLET MANIFOLD) | 1 | |
| 7P7913 | 26 MOUNT | 2 | |
| 1251303 | 27 SWITCH GP-MAGNETIC (12-VOLT)(AIR SHUTOFF) | 1 | |
| 1367829 | 28 BRACKET | 1 |
