System And Components
356-1440 RADIATOR GPS/N BDN1944-UP
Group No: 356-1440 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3048008 | 1 PLUG AS | 1 | |
| 6V9027 | SEAL-O-RING | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 4182234 | 2 GUARD AS-FAN | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3811717 | 3 RADIATOR GP | 1 | |
| 3545403 | 4 PLATE | 2 | |
| 3491209 | 5 CLIP | 3 | |
| 3650582 | 6 VALVE AS-SHUTOFF | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 6V7238 | VALVE-SHUTOFF | 1 | |
| 4165294 | 7 FILM-IDENTIFICATION (COOLANT CONDITIONER, READ OMM) | 1 | |
| 8T4222 | 8 WASHER-PLATED (11X32X2.5-MM THK) | 25 | |
| 7X0592 | 9 WASHER-HARD (10.2X32X5-MM THK) | 10 | |
| 8T4121 | 10 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4136 | 11 BOLT (M10X1.5X25-MM) | 26 | |
| 4182233 | 12 SHROUD AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 18 | |
| 1053484 | 13 BOLT-SOCKET HEAD (M10X1.5X25-MM) | 12 |
