System And Components
348-7015 MOUNTING GP-BELT TENSIONERPROVIDES AN ALTERNATOR AND REFRIGERANT COMPRESSOR MOUNTING BRACKET, AUTOMATIC BELT TENSIONER, IDLERS, AND MOUNTING HARDWARE FOR AN 8-RIB POLY-VEE ACCESSORY DRIVE
Group No: 348-7015
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2432310 | 1 COVER | 1 | |
| 3331207 | 2 IDLER AS | 1 | |
| 3477963 | 3 TENSIONER-BELT | 1 | |
| 3487014 | 4 BRACKET-SUPPORT | 1 | |
| 3487018 | 5 BRACKET | 1 | |
| 5P8245 | 6 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V2317 | 7 BOLT (M8X1.25X30-MM) | 2 | |
| 6V5839 | 8 WASHER (11X21X2.5-MM THK) | 9 | |
| 6V5842 | 9 BOLT (M10X1.5X40-MM) | 4 | |
| 6V8149 | 10 NUT (M12X1.75-THD) | 2 | |
| 8T0643 | 11 BOLT (M10X1.5X80-MM) | 4 | |
| 8T0644 | 12 BOLT (M10X1.5X90-MM) | 1 | |
| 9M1974 | 13 WASHER-HARD (8.8X16X2-MM THK) | 2 |
