System And Components
342-7845 PAN GP-OIL -REAR SUMPCONTAINS AN OIL PAN WITH OCV DRAIN PORTS ON THE OIL PAN FLANGE RAIL
Group No: 342-7845
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X6451 | 1 PLUG-DRAIN (MAGNETIC)(ENGINE OIL) | 2 | |
| 2101746 | 2 BELL AS-SUCTION | 1 | |
| 2101743 | ELBOW | 1 | |
| 2173673 | 3 SEAL-ISOLATION | 1 | |
| 3414951 | 4 PAN-OIL | 1 | |
| 0619458 | 5 SEAL-O-RING | 2 | |
| 2173674 | 6 FASTENER AS | 14 | |
| 2873049 | 7 STUD (M10X1.5X50-MM) | 1 | |
| 3072671 | 8 PLUG AS | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3196234 | 9 PLUG AS | 2 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3E8016 | 10 BOLT-SELF-LOCKING (M8X1.25X25-MM) | 2 | |
| 5P8211 | 11 SEAL-O-RING | 1 | |
| 5P8245 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6A5591 | 13 BOLT (M12X1.75X25-MM) | 4 | |
| 6N8863 | 14 WASHER (10.2X32X2.5-MM THK) | 14 | |
| 6V4249 | 15 BOLT (M10X1.5X50-MM) | 13 | |
| 9M1974 | 16 WASHER-HARD (8.8X16X2-MM THK) | 2 |
