Assembly
100%

351-6922 MOUNTING GP-RADIATORS/N KWJ4675-UP

Group No: 351-6922
Part NumberPart NameQty
8D37861 MOUNTING2
18607122 PLATE4
35169063 BRACE1
35169074 BRACE1
51389735 SUPPORT AS-RADIATOR1
51389726 SUPPORT AS-RADIATOR1
35216657 BRACKET1
35530958 BRACKET2
35530969 PLATE1
5P107610 WASHER-HARD (13.5X30X4-MM THK)16
7T833211 MOUNTING4
7X038312 BOLT (7/8-9X2.75-IN)8
7X061813 WASHER-HARD (13.5X40X5-MM THK)10
8C691314 WASHER-HARD (24X41.5X4-MM THK)8
8T413915 BOLT (M12X1.75X30-MM)2
8T418316 BOLT (M12X1.75X40-MM)4
8T422317 WASHER-HARD (13.5X25.5X3-MM THK)6
8T424418 NUT (M12X1.75-THD)14
8T464819 BOLT (M12X1.75X70-MM)2
8T489520 WASHER (13.5X50X5-MM THK)6
8T495621 BOLT (M12X1.75X35-MM)6
8T686822 BOLT (M12X1.75X80-MM)4
