System And Components
344-1783 WIRING GP-CEMPART OF 346-0144, 346-0151 MODULE AR-CLEAN EMISSIONS
Group No: 344-1783
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1271991 | 1 SPACER (8.2X13X15-MM THK) | 1 | |
| 2249222 | 2 BRACKET | 1 | |
| 2293177 | 3 PLATE AS | 1 | |
| 6V6716 | RIVET-TRUSS HEAD | 2 | |
| 1091645 | CLIP | 1 | |
| 2956239 | 4 WIRE AS-IGNITION | 1 | |
| 3150225 | 5 CLAMP-WIRE | 1 | |
| 3189355 | 6 MOUNTING-CABLE TIE | 1 | |
| 3264516 | 7 TIE-CABLE | 23 | |
| 3414176 | 8 SENSOR GP-TEMPERATURE (DUAL SENSOR- DPF, FLAME DETECT)(DPF INLET, FLAME DETECT) | 1 | |
| 8T9405 | 9 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 1 | |
| 3441199 | 10 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 3441200 | 11 WASHER-HARD (6.6X12X2-MM THK) | 4 | |
| 3521233 | 12 WIRING GP-CEM | 1 | |
| 3264516 | TIE-CABLE | 7 | |
| 3521234 | HARNESS AS-CEM | 1 | |
| 3E6446 | CAP AS-CONNECTOR | 1 | |
| 1106844 | SEAL | 1 | |
| 2L8078 | TERMINAL-RING (14-GA TO 16-GA, 5/16-IN SCREW) | 1 | |
| 8T8737 | PLUG-SEAL | 24 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(10-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(5-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 45 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 45 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 22 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 22 | |
| 2407876 | PLUG AS-CONNECTOR (2-PIN) | 2 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 2407877 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 2407878 | PLUG AS-CONNECTOR (3-PIN) | 2 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 2407879 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 2610524 | PLUG AS-CONNECTOR (4-PIN) | 1 | |
| 2647031 | SEAL-CONNECTOR | 1 | |
| 2813119 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 2813120 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 2813125 | PLUG AS-CONNECTOR (4-PIN) | 1 | |
| 2647031 | SEAL-CONNECTOR | 1 | |
| 2813132 | PLUG AS-CONNECTOR (6-PIN) | 1 | |
| 2647032 | SEAL-CONNECTOR | 1 | |
| 2813134 | PLUG AS-CONNECTOR (6-PIN) | 1 | |
| 2647032 | SEAL-CONNECTOR | 1 | |
| 2813395 | PLUG AS-CONNECTOR (12-PIN) | 1 | |
| 2647034 | SEAL-CONNECTOR | 1 | |
| 3264516 | TIE-CABLE | 2 | |
| 3522905 | 13 HARNESS AS-SENSOR | 1 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 6 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 6 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 6 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 6 | |
| 2813119 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 2813120 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 3524756 | 14 HARNESS AS-CEM (NOZZLE HEATER) | 1 | |
| 2856393 | 15 CLIP (LADDER) | 3 | |
| 2856395 | 16 CLIP (LADDER) | 2 | |
| 3118366 | 17 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 3160488 | 18 SPACER (11X25X78-MM THK) | 4 | |
| 3413624 | 19 CLIP (LADDER) | 7 | |
| 3441191 | 20 BOLT (M10X1.5X100-MM) | 4 | |
| 3441193 | 21 BOLT (M8X1.25X25-MM) | 2 | |
| 3441201 | 22 BOLT (M10X1.5X20-MM) | 1 | |
| 3441202 | 23 BOLT (M8X1.25X12-MM) | 1 | |
| 3441203 | 24 BOLT (M8X1.25X16-MM) | 1 | |
| 3441206 | 25 BOLT (M6X1X16-MM) | 4 | |
| 3441208 | 26 BOLT (M6X1X35-MM) | 1 |
