Assembly
100%

356-4177 WIRING GP-CEMPROVIDES AN INTERCONNECT WIRING GP BETWEEN THE MAIN ENGINE HARNESS, 12-VOLT AND 24-VOLT LH SIDE PRIMARY HARNESS, SOOT SENSOR HARNESS, AND CEM HARNESS FOR ENGINES WITH ENGINE MOUNTED ECM

Group No: 356-4177
Part NumberPart NameQty
3S20931 STRAP-CABLE14
6K08062 STRAP-CABLE1
18342743 BRACKET1
31612474 STRAP-CABLE3
35652135 HARNESS AS-CEM1
1S9593STRAP-CABLE4
3E5226SOCKET-CONNECTOR (12-GA TO 14-GA)2
8T8737PLUG-SEAL22
9X1054PLUG AS-CONNECTOR (4-PIN)1
9X1055TERMINAL-RECEPTACLE (12-GA)2
1005041TERMINAL-RECEPTACLE (18-GA TO 20-GA)2
1153519PIN-CONNECTOR (12-GA TO 14-GA)2
1193662TUBE-HEAT SHRINK (10.85-MM DIA)(7-CM)
1257874TUBE-HEAT SHRINK (5.72-MM DIA)(30-CM)
1257875TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM)
9X3402SOCKET-CONNECTOR (16-GA TO 18-GA)76
1261768SOCKET-CONNECTOR (14-GA TO 16-GA)76
1311507TERMINAL AS-RING1
1257874TUBE-HEAT SHRINK (5.72-MM DIA)(3-CM)
1342540RECEPTACLE AS-CONNECTOR (3-PIN)1
9X3401PIN-CONNECTOR (16-GA TO 18-GA)2
1261767PIN-CONNECTOR (14-GA TO 16-GA)2
1552260KIT-CONNECTING PLUG (3-PIN)1
1779645KIT-RECEPTACLE (2-PIN)1
1779648KIT-CONNECTING PLUG (2-PIN)1
2304011PLUG AS-CONNECTOR (2-PIN)2
2647029SEAL-CONNECTOR1
2304012RECEPTACLE AS-CONNECTOR (2-PIN)1
2397349PLUG AS-CONNECTOR (4-PIN)1
2647031SEAL-CONNECTOR1
2714923PLUG AS-CONNECTOR1
8T8737PLUG-SEAL2
1779648KIT-CONNECTING PLUG (2-PIN)1
2818811PLUG AS-CONNECTOR (6-PIN)1
2647032SEAL-CONNECTOR1
2895150SLEEVE (36-CM)
2895151SLEEVE (24-CM)
3171204SLEEVE (60-CM)
3246266PLUG AS-CONNECTOR (40-PIN)2
1106844SEAL1
13257896 CLIP (LADDER)4
5C72617 NUT (M8X1.25-THD)2
8T06428 BOLT (M8X1.25X14-MM)3
8T41899 BOLT (M8X1.25X20-MM)1
8T419210 BOLT (M12X1.75X25-MM)1
8T422311 WASHER-HARD (13.5X25.5X3-MM THK)3
8T422412 WASHER-HARD (8.8X16X2-MM THK)6
