System And Components
344-5112 FILTER GP-FUMES DISPOSALPROVIDE AN OPEN CRANKCASE FILTER SYSTEM TO CLEAN THE ENGINE BLOW BY GAS AND RETURN THE OIL BACK TO THE CRANKCASE
Group No: 344-5112
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2416160 | 1 TEE | 1 | |
| 3428949 | 2 VALVE | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3470547 | 3 FILTER GP-FUMES DISPOSAL | 2 | |
| 3479451 | 4 BRACKET | 1 | |
| 3479454 | 5 TUBE AS-OIL | 1 | |
| 3479455 | 6 TUBE AS-OIL | 1 | |
| 3479464 | 7 PLATE | 1 | |
| 3479465 | 8 PLATE | 1 | |
| 3489705 | 9 VALVE AS-CHECK | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3504461 | 10 HOSE AS | 1 | |
| 3504462 | 11 HOSE AS | 1 | |
| 0S1571 | 12 BOLT (3/8-16X1.75-IN) | 3 | |
| 0S1594 | 13 BOLT (3/8-16X1-IN) | 9 | |
| 1248909 | 14 ELBOW | 1 | |
| 1F4111 | 15 BOLT (5/16-18X3.5-IN) | 1 | |
| 2022762 | 16 CLIP (LOOP) | 4 | |
| 2147566 | 17 SEAL-O-RING | 2 | |
| 3250106 | 18 CLIP | 1 | |
| 4F0411 | 19 BOLT (3/8-16X6.5-IN) | 4 | |
| 5M2894 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 17 | |
| 5V9155 | 21 CLAMP-HOSE | 4 | |
| 7C9900 | 22 SPACER (11.48X13.72X65-MM THK) | 1 | |
| 8T4983 | 23 CLAMP-HOSE | 4 | |
| 9M1974 | 24 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9S8752 | 25 NUT-FULL (3/8-16-THD) | 1 | |
| 5P1505 | 26 HOSE (39.6-CM) | ||
| 5P1505 | 26A HOSE (32.7-CM) |
