System And Components
377-2252 FUMES DISPOSAL GPType 1
Group No: 377-2252
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1013121 | 1 SPACER (10.5X25X25-MM THK) | 1 | |
| 3539663 | 2 SPACER (10.5X22X80-MM THK) | 2 | |
| 3771640 | 3 TUBE | 1 | |
| 3771641 | 4 TUBE | 1 | |
| 3771642 | 5 HOSE | 1 | |
| 3771643 | 6 HOSE | 1 | |
| 3771644 | 7 BRACKET | 4 | |
| 0340912 | 8 TUBE | 1 | |
| 8T9379 | 9 BOLT (3/8-16X4.25-IN) | 2 | |
| 1246265 | 10 CLAMP-HOSE | 2 | |
| 7X0293 | 11 BOLT (3/8-16X4.75-IN) | 1 | |
| 7X0294 | 12 BOLT (3/8-16X5-IN) | 1 | |
| 5P7468 | 13 CLIP (SLOT) | 4 | |
| 5P7469 | 14 CLIP (TAB) | 4 | |
| 6V1874 | 15 GROMMET (31-MM ID) | 4 | |
| 8T1117 | 16 CLAMP-HOSE | 2 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4244 | 18 NUT (M12X1.75-THD) | 4 | |
| 8T4956 | 19 BOLT (M12X1.75X35-MM) | 4 | |
| 0398557 | 20 WASHER (13X26X6-MM THK) | 2 | |
| 5P1075 | 21 WASHER-HARD (10.2X22.5X3-MM THK) | 2 |
