377-2252 FUMES DISPOSAL GPType 2

Group No: 377-2252
Part NumberPart NameQty
35396631 SPACER (10.5X22X80-MM THK)2
37716402 TUBE1
37716413 TUBE1
37716424 HOSE1
37716435 HOSE1
37716446 BRACKET3
42292947 BRACKET1
5P10768 WASHER-HARD (13.5X30X4-MM THK)2
6V88019 NUT (3/8-16-THD)2
124626510 CLAMP-HOSE2
5P107511 WASHER-HARD (10.2X22.5X3-MM THK)2
5P746812 CLIP (SLOT)3
5P746913 CLIP (TAB)3
6V187414 GROMMET (31-MM ID)4
8T418415 BOLT (M12X1.75X45-MM)1
8T489616 WASHER-HARD (10.2X18.5X2.5-MM THK)2
8T111717 CLAMP-HOSE2
8T422318 WASHER-HARD (13.5X25.5X3-MM THK)6
8T424419 NUT (M12X1.75-THD)4
8T495620 BOLT (M12X1.75X35-MM)3
8T937921 BOLT (3/8-16X4.25-IN)2
9D619622 CLIP (SLOT)1
9D619723 CLIP (TAB)1
