System And Components
385-3426 FUMES DISPOSAL GPType 2
Group No: 385-3426
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3539663 | 1 SPACER (10.5X22X80-MM THK) | 1 | |
| 3853432 | 2 TUBE | 1 | |
| 3898067 | 3 HOSE-TEE | 1 | |
| 3903084 | 4 TUBE | 1 | |
| 1246264 | 5 CLAMP-HOSE | 3 | |
| 1333260 | 6 SPACER (11X19X10-MM THK) | 3 | |
| 2426099 | 7 CLIP (LOOP) | 3 | |
| 5P0597 | 8 CLAMP-HOSE | 2 | |
| 5P1075 | 9 WASHER-HARD (10.2X22.5X3-MM THK) | 1 | |
| 5P7468 | 10 CLIP (SLOT) | 2 | |
| 5P7469 | 11 CLIP (TAB) | 2 | |
| 5P8444 | 12 GROMMET (37-MM ID) | 2 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4133 | 14 NUT (M10X1.5-THD) | 3 | |
| 8T4196 | 15 BOLT (M10X1.5X35-MM) | 3 | |
| 8T9379 | 16 BOLT (3/8-16X4.25-IN) | 1 | |
| 1394255 | 17 SPACER (10X20X7-MM THK) | 1 | |
| 4229294 | 18 BRACKET | 1 | |
| 6V8801 | 19 NUT (3/8-16-THD) | 1 | |
| 8T4244 | 20 NUT (M12X1.75-THD) | 1 | |
| 8T4183 | 21 BOLT (M12X1.75X40-MM) | 1 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4896 | 23 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5P1469 | 24 HOSE (71-CM) |
