System And Components
371-9419 LINES GP-ENGINE OILAN ATTACHMENT
Group No: 371-9419
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W4755 | 1 ADAPTER | 1 | |
| 2P3760 | 2 GASKET | 1 | |
| 2P3761 | 3 COVER | 1 | |
| 3H9269 | 4 SPACER (19.05X3.05X17.48-MM THK) | 1 | |
| 4N0913 | 5 SCREEN-STRAINER | 1 | |
| 4N0914 | 6 CLIP | 1 | |
| 4N8150 | 7 SPRING | 1 | |
| 6N0448 | 8 MANIFOLD | 1 | |
| 6N0452 | 9 ELBOW-COOLER OUTLET | 1 | |
| 6N0624 | 10 TUBE AS-OUTLET | 1 | |
| 8N2104 | 11 BELL AS-SUCTION | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 8N6739 | 12 RING-RETAINING | 1 | |
| 8N6740 | 13 RETAINER | 2 | |
| 9L6842 | 14 TUBE AS | 1 | |
| 9M0853 | 15 PLUNGER-VALVE | 1 | |
| 1160765 | 16 TUBE AS-OIL PUMP | 1 | |
| 1162698 | 17 TUBE AS | 1 | |
| 1295225 | 18 SUPPORT-SUCTION BELL | 1 | |
| 3719527 | 19 TUBE AS | 1 | |
| 0L1351 | 20 BOLT (3/8-16X0.875-IN) | 3 | |
| 0L2070 | 21 BOLT (3/8-16X2.25-IN) | 5 | |
| 0S1571 | 22 BOLT (3/8-16X1.75-IN) | 1 | |
| 0S1590 | 23 BOLT (3/8-16X2-IN) | 1 | |
| 0S1591 | 24 BOLT (3/8-16X1.5-IN) | 1 | |
| 0S1594 | 25 BOLT (3/8-16X1-IN) | 7 | |
| 1090072 | 26 SEAL-O-RING | 1 | |
| 1090076 | 27 SEAL-O-RING | 4 | |
| 1090078 | 28 SEAL-O-RING | 4 | |
| 1A2029 | 29 BOLT (3/8-16X1.125-IN) | 4 | |
| 4N0933 | 30 GASKET | 1 | |
| 5M2894 | 31 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 6V3830 | 32 SEAL-O-RING | 2 | |
| 8M9024 | 33 WASHER-HARD (10.2X22.5X5-MM THK) | 1 |
