System And Components
348-2273 LINES GP-TURBOCHARGER OILPROVIDES OIL SUPPLY AND DRAIN LINES TO LUBE THE TURBO BEARINGS
Group No: 348-2273
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N9008 | 1 ELBOW | 1 | |
| 8N0590 | 2 CLIP | 4 | |
| 1978418 | 3 GASKET | 2 | |
| 3502837 | 4 ELBOW | 1 | |
| 4641132 | 5 HOSE & TUBE AS | 1 | |
| 4641133 | 6 HOSE & TUBE AS | 1 | |
| 3643830 | 7 TUBE AS | 1 | |
| 3646459 | 8 TUBE AS | 1 | |
| 0S1616 | 9 BOLT (1/4-20X1-IN) | 2 | |
| 1123540 | 10 SEAL-O-RING | 2 | |
| 1978419 | 11 GASKET | 2 | |
| 1B2790 | 12 BOLT (5/16-18X1.375-IN) | 8 | |
| 2609219 | 13 CONNECTOR AS | 2 | |
| 6V8638 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3B1915 | 14 BOLT (3/8-16X1.375-IN) | 4 | |
| 5P0537 | 15 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 5P5846 | 16 SEAL-O-RING | 2 | |
| 9M1974 | 17 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 9S8750 | 18 NUT-FULL (1/4-20-THD) | 2 | |
| 1984775 | 19 WASHER-HARD (6.6X15X6-MM THK) | 2 |
