System And Components
348-2274 LINES GP-TURBOCHARGER OILS/N RAM106-UP
Group No: 348-2274
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N0590 | 1 CLIP | 4 | |
| 1978418 | 2 GASKET | 2 | |
| 7N9008 | 3 ELBOW | 1 | |
| 4409184 | 4 ADAPTER | 1 | |
| 4641132 | 5 HOSE & TUBE AS | 1 | |
| 4641133 | 6 HOSE & TUBE AS | 1 | |
| 3643830 | 7 TUBE AS | 1 | |
| 4203421 | 8 HOSE & TUBE AS | 1 | |
| 0S1616 | 9 BOLT (1/4-20X1-IN) | 2 | |
| 1123540 | 10 SEAL-O-RING | 1 | |
| 1978419 | 11 GASKET | 2 | |
| 1B2790 | 12 BOLT (5/16-18X1.375-IN) | 8 | |
| 2609219 | 13 CONNECTOR AS | 2 | |
| 6V8638 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3985610 | 14 CONNECTOR AS | 1 | |
| 3R6790 | CONNECTOR-PORT | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 1653929 | 15 BOLT (3/8-16X1.5-IN) | 4 | |
| 5P0537 | 16 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 5P5846 | 17 SEAL-O-RING | 2 | |
| 4203423 | 18 TUBE AS-OIL | 1 | |
| 9M1974 | 19 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 9S8750 | 20 NUT-FULL (1/4-20-THD) | 2 | |
| 1984775 | 21 WASHER-HARD (6.6X15X6-MM THK) | 2 | |
| 5M2894 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 |
