System And Components
348-2278 LINES GP-TURBOCHARGER OILPROVIDES OIL SUPPLY AND DRAIN LINES TO LUBE THE TURBO BEARINGS
Group No: 348-2278
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N9008 | 1 ELBOW | 2 | |
| 8N0590 | 2 CLIP | 4 | |
| 1978418 | 3 GASKET | 2 | |
| 1978419 | 4 GASKET | 2 | |
| 3510917 | 5 TUBE AS | 1 | |
| 3641937 | 6 TUBE AS | 1 | |
| 3641939 | 7 HOSE & TUBE AS | 1 | |
| 3644484 | 8 HOSE & TUBE AS | 1 | |
| 0S1616 | 9 BOLT (1/4-20X1-IN) | 2 | |
| 1123540 | 10 SEAL-O-RING | 2 | |
| 1B2790 | 11 BOLT (5/16-18X1.375-IN) | 8 | |
| 3B1915 | 12 BOLT (3/8-16X1.375-IN) | 4 | |
| 5P0537 | 13 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 5P5846 | 14 SEAL-O-RING | 2 | |
| 2609219 | 15 CONNECTOR AS | 2 | |
| 6V8638 | 15A CONNECTOR | 1 | |
| 2287090 | 15B SEAL-O-RING | 1 | |
| 2385081 | 15C SEAL-O-RING | 1 | |
| 9M1974 | 16 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 9S8750 | 17 NUT-FULL (1/4-20-THD) | 2 |
