System And Components
348-2277 LINES GP-TURBOCHARGER WATERS/N RAM1-105
Group No: 348-2277
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2385080 | 1 SEAL-O-RING | 3 | |
| 3518277 | 2 HOSE AS | 1 | |
| 3518279 | 3 TUBE AS | 1 | |
| 3554675 | 4 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3554676 | 5 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3554677 | 6 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3554678 | 7 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3554679 | 8 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3554681 | 9 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3554682 | 10 HOSE AS | 1 | |
| 3554683 | 11 HOSE AS | 1 | |
| 3554686 | 12 TUBE AS | 1 | |
| 3554687 | 13 TUBE AS | 1 | |
| 3559857 | 14 TUBE AS | 1 | |
| 3568223 | 15 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3572583 | 16 HOSE AS | 1 | |
| 0307959 | 17 TEE-FLARED | 1 | |
| 0308110 | 18 CONNECTOR | 2 | |
| 0308189 | 19 CONNECTOR | 1 | |
| 0S0509 | 20 BOLT (3/8-16X0.75-IN) | 6 | |
| 0S1594 | 21 BOLT (3/8-16X1-IN) | 3 | |
| 0S1619 | 22 BOLT (3/8-16X3-IN) | 1 | |
| 2385082 | 23 SEAL-O-RING | 1 | |
| 2385084 | 24 SEAL-O-RING | 1 | |
| 2P8430 | 25 CONNECTOR | 1 | |
| 3079615 | 26 ADAPTER AS | 2 | |
| 8M0505 | 26A ADAPTER | 1 | |
| 2385080 | 26B SEAL-O-RING | 1 | |
| 3118802 | 27 SPACER (10.5X19X57-MM THK) | 1 | |
| 3491209 | 28 CLIP | 5 | |
| 4H2633 | 29 CLIP | 3 | |
| 5M2894 | 30 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 8M0547 | 31 ELBOW-FLARED (SWIVEL) | 2 |
