System And Components
348-2277 LINES GP-TURBOCHARGER WATERS/N RAM106-UP
Group No: 348-2277
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P7233 | 1 GROMMET | 4 | |
| 1178990 | 2 CLIP | 2 | |
| 3855632 | 3 TUBE AS-WATER | 1 | |
| 3857034 | 4 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3554677 | 5 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3554678 | 6 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 4287868 | 7 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 4260201 | 8 HOSE & TUBE AS | 1 | |
| 3857035 | 9 BRACKET AS | 1 | |
| 3554687 | 10 TUBE AS | 1 | |
| 3649282 | 11 HOSE & TUBE AS | 1 | |
| 3649285 | 12 TUBE AS | 1 | |
| 4196162 | 13 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3676009 | 14 ADAPTER | 1 | |
| 3717252 | 15 TUBE AS-WATER | 1 | |
| 3869666 | 16 TUBE AS-WATER | 1 | |
| 0307959 | 17 TEE-FLARED | 1 | |
| 0321270 | 18 TEE | 1 | |
| 0L1351 | 19 BOLT (3/8-16X0.875-IN) | 4 | |
| 0S0509 | 20 BOLT (3/8-16X0.75-IN) | 1 | |
| 0S1588 | 21 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1594 | 22 BOLT (3/8-16X1-IN) | 2 | |
| 3939338 | 23 HOSE & TUBE AS | 1 | |
| 1A2029 | 24 BOLT (3/8-16X1.125-IN) | 1 | |
| 2P8430 | 25 CONNECTOR | 1 | |
| 5S0003 | 26 NUT (5/16-18-THD) | 1 | |
| 3491209 | 27 CLIP | 2 | |
| 3535130 | 28 ADAPTER AS | 2 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 8M0505 | ADAPTER | 1 | |
| 3P2298 | 29 ELBOW-FLARED | 1 | |
| 9M1974 | 30 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 5M2894 | 31 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 6V5063 | 32 SEAL-O-RING | 1 | |
| 6V5064 | 33 SEAL-O-RING | 1 | |
| 6V6609 | 34 SEAL-O-RING | 3 | |
| 8M0547 | 35 ELBOW-FLARED (SWIVEL) | 4 | |
| 8M3175 | 36 WASHER-HARD (10.2X16X3-MM THK) | 2 | |
| 8S4951 | 37 CAP (FLARED) | 1 | |
| 8T1887 | 38 CLIP (SLOT) | 4 | |
| 8T1888 | 39 CLIP (TAB) | 4 | |
| 9D2673 | 40 CONNECTOR-PORT | 2 | |
| 9F6343 | 41 CLAMP | 2 | |
| 9S8752 | 42 NUT-FULL (3/8-16-THD) | 3 | |
| 3735824 | 43 HOSE & TUBE AS | 1 |
