System And Components
355-5614 LINES GP-TURBOCHARGER WATERPROVIDES WATER SUPPLY LINES GROUP TO LUBE THE TURBO BEARINGS FOR C27 A-TIER INDUSTRIAL APPLICATIONS
Group No: 355-5614
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P7233 | 1 GROMMET | 2 | |
| 8N0590 | 2 CLIP | 2 | |
| 3554675 | 3 BRACKET AS | 1 | |
| 3554676 | 4 BRACKET AS | 1 | |
| 3554677 | 5 BRACKET AS | 1 | |
| 3554678 | 6 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3554684 | 7 HOSE AS-WATER | 1 | |
| 3554686 | 8 TUBE AS | 1 | |
| 3554687 | 9 TUBE AS | 1 | |
| 3646733 | 10 HOSE & TUBE AS | 1 | |
| 3646734 | 11 HOSE & TUBE AS | 1 | |
| 3646739 | 12 TUBE AS | 1 | |
| 3653499 | 13 BRACKET AS | 1 | |
| 3716735 | 14 HOSE & TUBE AS | 1 | |
| 3717252 | 15 TUBE AS-WATER | 1 | |
| 0307959 | 16 TEE-FLARED | 1 | |
| 0321270 | 17 TEE | 1 | |
| 0L1351 | 18 BOLT (3/8-16X0.875-IN) | 2 | |
| 0S0509 | 19 BOLT (3/8-16X0.75-IN) | 4 | |
| 0S1571 | 20 BOLT (3/8-16X1.75-IN) | 1 | |
| 0S1588 | 21 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1594 | 22 BOLT (3/8-16X1-IN) | 2 | |
| 0S1616 | 23 BOLT (1/4-20X1-IN) | 1 | |
| 0S1619 | 24 BOLT (3/8-16X3-IN) | 2 | |
| 0T0065 | 25 BOLT (3/8-16X3.5-IN) | 1 | |
| 1B5964 | 26 SPACER | 1 | |
| 1S0724 | 27 CLIP | 1 | |
| 2P8430 | 28 CONNECTOR | 1 | |
| 3118802 | 29 SPACER (10.5X19X57-MM THK) | 2 | |
| 3491209 | 30 CLIP | 4 | |
| 3535130 | 31 ADAPTER AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 8M0505 | ADAPTER | 1 | |
| 3P2298 | 32 ELBOW-FLARED | 1 | |
| 4H2633 | 33 CLIP | 4 | |
| 5L7674 | 34 SPACER (12.5X17.1X69.85-MM THK) | 1 | |
| 5M2894 | 35 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 5P0537 | 36 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 6V5063 | 37 SEAL-O-RING | 1 | |
| 6V5064 | 38 SEAL-O-RING | 1 | |
| 6V6609 | 39 SEAL-O-RING | 4 | |
| 8M0547 | 40 ELBOW-FLARED (SWIVEL) | 3 | |
| 8M3175 | 41 WASHER-HARD (10.2X16X3-MM THK) | 4 | |
| 8S4951 | 42 CAP (FLARED) | 1 | |
| 8T1887 | 43 CLIP (SLOT) | 2 | |
| 8T1888 | 44 CLIP (TAB) | 2 | |
| 9D2673 | 45 CONNECTOR-PORT | 3 | |
| 9F6343 | 46 CLAMP | 4 | |
| 9S8750 | 47 NUT-FULL (1/4-20-THD) | 1 | |
| 9S8752 | 48 NUT-FULL (3/8-16-THD) | 3 |
