System And Components
364-0887 LINES GP-TURBOCHARGER WATERS/N RAM114-UP
Group No: 364-0887
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P7233 | 1 GROMMET | 2 | |
| 8S4951 | 2 CAP (FLARED) | 1 | |
| 6V6609 | 3 SEAL-O-RING | 3 | |
| 3554679 | 5 BRACKET AS | 1 | |
| 3554675 | 6 BRACKET AS | 1 | |
| 1F0750 | 6A NUT-WELD (3/8-16-THD) | 1 | |
| 3554676 | 7 BRACKET AS | 1 | |
| 1F0750 | 7A NUT-WELD (3/8-16-THD) | 1 | |
| 3554677 | 8 BRACKET AS | 1 | |
| 1F0750 | 8A NUT-WELD (3/8-16-THD) | 1 | |
| 3554678 | 9 BRACKET AS | 1 | |
| 1F0750 | 9A NUT-WELD (3/8-16-THD) | 1 | |
| 3801332 | 10 HOSE AS-WATER | 1 | |
| 3554686 | 11 TUBE AS | 1 | |
| 3554683 | 12 HOSE AS | 1 | |
| 3554687 | 13 TUBE AS | 1 | |
| 3717252 | 14 TUBE AS-WATER | 1 | |
| 3653499 | 15 BRACKET AS | 1 | |
| 3646739 | 16 TUBE AS | 1 | |
| 3735824 | 17 HOSE & TUBE AS | 1 | |
| 3802049 | 18 HOSE & TUBE AS | 1 | |
| 0307959 | 19 TEE-FLARED | 1 | |
| 0321270 | 21 TEE | 1 | |
| 0S0509 | 22 BOLT (3/8-16X0.75-IN) | 4 | |
| 0S1571 | 23 BOLT (3/8-16X1.75-IN) | 1 | |
| 0S1588 | 24 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1594 | 25 BOLT (3/8-16X1-IN) | 4 | |
| 0S1619 | 26 BOLT (3/8-16X3-IN) | 1 | |
| 1B5964 | 29 SPACER | 1 | |
| 6V5063 | 30 SEAL-O-RING | 1 | |
| 6V5064 | 31 SEAL-O-RING | 1 | |
| 2P8430 | 32 CONNECTOR | 1 | |
| 3535130 | 33 ADAPTER AS | 2 | |
| 8M0505 | 33A ADAPTER | 1 | |
| 6V6609 | 33B SEAL-O-RING | 1 | |
| 3118802 | 34 SPACER (10.5X19X57-MM THK) | 1 | |
| 3491209 | 35 CLIP | 5 | |
| 3P2298 | 36 ELBOW-FLARED | 1 | |
| 4H2633 | 37 CLIP | 1 | |
| 5M2894 | 38 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 8M0547 | 39 ELBOW-FLARED (SWIVEL) | 4 | |
| 8M3175 | 40 WASHER-HARD (10.2X16X3-MM THK) | 2 | |
| 8T1887 | 41 CLIP (SLOT) | 2 | |
| 8T1888 | 42 CLIP (TAB) | 2 | |
| 9D2673 | 43 CONNECTOR-PORT | 2 | |
| 9F6343 | 44 CLAMP | 2 | |
| 9S8752 | 45 NUT-FULL (3/8-16-THD) | 1 | |
| 0L1351 | 46 BOLT (3/8-16X0.875-IN) | 1 | |
| 3676009 | 47 ADAPTER | 1 |
