348-0392 LINES GP-WATERNOX REDUCTION SYSTEM COOLER

Group No: 348-0392
Part NumberPart NameQty
1W70201 RING-RETAINING3
2W40322 RETAINER3
7C18223 COUPLING1
34388884 GASKET1
34599115 COVER2
34803816 ELBOW1
34803827 ELBOW1
34803838 TUBE1
34803849 BONNET1
348038510 ELBOW1
348038711 ELBOW1
348038912 TUBE1
348039013 ELBOW1
348346714 ELBOW1
348346815 TUBE AS1
348346916 TUBE AS1
348440517 TUBE AS1
348440718 TUBE1
348440819 TUBE AS1
350673620 BRACKET AS1
1F0748NUT-WELD (1/2-13-THD)1
352037221 TUBE AS1
355159622 SEAL-O-RING2
030794123 ELBOW1
030794624 ELBOW2
0L114325 BOLT (3/8-16X2.5-IN)3
0S158826 BOLT (3/8-16X1.25-IN)4
0S159127 BOLT (3/8-16X1.5-IN)2
0S159428 BOLT (3/8-16X1-IN)13
0S159529 BOLT (1/2-13X1.25-IN)1
0S161930 BOLT (3/8-16X3-IN)6
118650331 BOLT (M6X1X55-MM)1
143453532 CLIP (SLOT)2
143453633 CLIP (TAB)2
164687534 ELBOW AS1
3J7354SEAL-O-RING1
0307946ELBOW1
1A202935 BOLT (3/8-16X1.125-IN)1
226357136 SEAL-O-RING3
241620537 PLUG1
2B240438 CLIP3
3J190739 SEAL-O-RING1
3K036040 SEAL-O-RING1
4S485741 TEE1
5M289442 WASHER-HARD (10.2X18.5X2.5-MM THK)19
5P824543 WASHER-HARD (13.5X25.5X3-MM THK)1
6K493444 CLIP (SLOT)2
6K493545 CLIP (TAB)2
6V526646 SEAL-O-RING2
6V821447 BOLT (M6X1X20-MM)2
6V902748 SEAL-O-RING4
7L658049 SEAL-O-RING11
7M832250 CLIP1
8T064051 BOLT (M6X1X30-MM)1
8T958852 SEAL-O-RING1
9R538353 BOSS2
9S419154 PLUG (9/16-18-THD)1
9S875255 NUT-FULL (3/8-16-THD)2
9X645856 WASHER-HARD (10.2X22.5X3-MM THK)6
9X826757 WASHER (6.6X12X2-MM THK)4
