348-0392 LINES GP-WATERNOX REDUCTION SYSTEM COOLER

Group No: 348-0392
Part NumberPart NameQty
1W70201 RING-RETAINING2
2W40322 RETAINER2
7C18223 COUPLING1
34388884 GASKET1
34599115 COVER1
34803816 ELBOW1
34803827 ELBOW1
34803848 BONNET1
34803859 ELBOW1
348038710 ELBOW1
348038911 TUBE1
348039012 ELBOW1
348346713 ELBOW1
348440514 TUBE AS1
348440815 TUBE AS1
355159616 SEAL-O-RING2
362780217 TUBE AS1
364376318 BRACKET1
364917519 TUBE AS-WATER1
365612220 TUBE AS1
365753521 TUBE1
365753622 TUBE1
030794123 ELBOW1
030794624 ELBOW2
0L114325 BOLT (3/8-16X2.5-IN)3
0L207026 BOLT (3/8-16X2.25-IN)1
0S158827 BOLT (3/8-16X1.25-IN)1
0S159028 BOLT (3/8-16X2-IN)1
0S159429 BOLT (3/8-16X1-IN)6
0S159530 BOLT (1/2-13X1.25-IN)1
0S161931 BOLT (3/8-16X3-IN)6
118650332 BOLT (M6X1X55-MM)1
129317233 STUD-MOUNTING (3/8-16X1.564-IN)1
133326034 SPACER (11X19X10-MM THK)2
148174035 ELBOW1
1A202936 BOLT (3/8-16X1.125-IN)4
1F795837 NUT-FULL (1/2-13-THD)1
226357138 SEAL-O-RING3
241620539 PLUG1
363025340 CLIP (TAB)4
363025441 CLIP (SLOT)4
3B191542 BOLT (3/8-16X1.375-IN)2
6V325043 SEAL-O-RING1
4S485745 TEE1
5M289446 WASHER-HARD (10.2X18.5X2.5-MM THK)15
5P824547 WASHER-HARD (13.5X25.5X3-MM THK)2
6K493449 CLIP (SLOT)2
6K493550 CLIP (TAB)2
4J899851 SEAL-O-RING1
6V660952 SEAL-O-RING2
6V821453 BOLT (M6X1X20-MM)2
6V902754 SEAL-O-RING4
7L658055 SEAL-O-RING11
8E549856 BOSS1
8M902457 WASHER-HARD (10.2X22.5X5-MM THK)1
8T064058 BOLT (M6X1X30-MM)1
8T302060 CONNECTOR1
8T958861 SEAL-O-RING1
9L911562 STUD1
9S419163 PLUG (9/16-18-THD)1
9X645864 WASHER-HARD (10.2X22.5X3-MM THK)4
9X826765 WASHER (6.6X12X2-MM THK)4
