System And Components
371-6012 LINES GP-WATERNRS COOLER
Group No: 371-6012
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W7020 | 1 RING-RETAINING | 2 | |
| 2W4032 | 2 RETAINER | 2 | |
| 7C1822 | 3 COUPLING | 1 | |
| 3438888 | 4 GASKET | 1 | |
| 3459911 | 5 COVER | 1 | |
| 3480381 | 6 ELBOW | 1 | |
| 3480382 | 7 ELBOW | 1 | |
| 3480384 | 8 BONNET | 1 | |
| 3480385 | 9 ELBOW | 1 | |
| 3480387 | 10 ELBOW | 1 | |
| 3480389 | 11 TUBE | 1 | |
| 3480390 | 12 ELBOW | 1 | |
| 3483467 | 13 ELBOW | 1 | |
| 3484405 | 14 TUBE AS | 1 | |
| 3484408 | 15 TUBE AS | 1 | |
| 3529409 | 16 BRACKET | 1 | |
| 3551596 | 17 SEAL-O-RING | 2 | |
| 3627802 | 18 TUBE AS | 1 | |
| 3649175 | 19 TUBE AS-WATER | 1 | |
| 3656122 | 20 TUBE AS | 1 | |
| 3657535 | 21 TUBE | 1 | |
| 3712225 | 22 TUBE | 1 | |
| 0307941 | 23 ELBOW | 1 | |
| 0307946 | 24 ELBOW | 1 | |
| 0L1143 | 25 BOLT (3/8-16X2.5-IN) | 4 | |
| 0S1588 | 26 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1590 | 27 BOLT (3/8-16X2-IN) | 1 | |
| 0S1594 | 28 BOLT (3/8-16X1-IN) | 4 | |
| 0S1595 | 29 BOLT (1/2-13X1.25-IN) | 1 | |
| 0S1619 | 30 BOLT (3/8-16X3-IN) | 6 | |
| 0T0772 | 31 BOLT (7/16-14X1.5-IN) | 2 | |
| 1186503 | 32 BOLT (M6X1X55-MM) | 1 | |
| 1293172 | 33 STUD-MOUNTING (3/8-16X1.564-IN) | 1 | |
| 1333260 | 34 SPACER (11X19X10-MM THK) | 2 | |
| 1481740 | 35 ELBOW | 1 | |
| 1488407 | 36 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1646875 | 37 ELBOW AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 0307946 | ELBOW | 1 | |
| 1A2029 | 38 BOLT (3/8-16X1.125-IN) | 4 | |
| 1F7958 | 39 NUT-FULL (1/2-13-THD) | 1 | |
| 2263571 | 40 SEAL-O-RING | 3 | |
| 2416205 | 41 PLUG | 1 | |
| 3630253 | 42 CLIP (TAB)(TAB) | 4 | |
| 3630254 | 43 CLIP (SLOT)(SLOT) | 4 | |
| 3B1915 | 44 BOLT (3/8-16X1.375-IN) | 1 | |
| 6V6609 | 45 SEAL-O-RING | 2 | |
| 4S4857 | 46 TEE | 1 | |
| 5M2894 | 47 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 5P8244 | 48 WASHER-HARD (12X22.5X2.5-MM THK) | 2 | |
| 5P8245 | 49 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6K4934 | 51 CLIP (SLOT) | 2 | |
| 6K4935 | 52 CLIP (TAB) | 2 | |
| 4J8998 | 53 SEAL-O-RING | 1 | |
| 9X8267 | 54 WASHER (6.6X12X2-MM THK) | 4 | |
| 6V8214 | 55 BOLT (M6X1X20-MM) | 2 | |
| 6V9027 | 56 SEAL-O-RING | 3 | |
| 7L6580 | 57 SEAL-O-RING | 11 | |
| 8E5498 | 58 BOSS | 1 | |
| 8T0640 | 59 BOLT (M6X1X30-MM) | 1 | |
| 0308188 | 60 CONNECTOR | 1 | |
| 8T4121 | 61 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T9588 | 62 SEAL-O-RING | 1 | |
| 9L9115 | 63 STUD | 1 | |
| 9X6458 | 64 WASHER-HARD (10.2X22.5X3-MM THK) | 3 |
