351-8414 LINES GP-TURBOCHARGERPROVIDES A GROUP TO CREATE A PRESSURE REFERENCE CIRCUIT FROM MIXER THROUGH BALANCE VALVE SOLENOID, TO BALANACE VALVE ACTUATOR
Group No: 351-8414
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3642003 | 1 TUBE AS-AIR | 1 | |
| 3642007 | 2 TUBE AS-AIR | 1 | |
| 3642009 | 3 TUBE AS-AIR | 1 | |
| 3642010 | 4 TUBE AS-AIR | 1 | |
| 3642011 | 5 TUBE AS-AIR | 1 | |
| 3642015 | 6 TUBE AS-AIR | 1 | |
| 3649634 | 7 ELBOW AS | 1 | |
| 1716469 | ELBOW | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3649622 | 8 CONNECTOR AS | 1 | |
| 2147567 | SEAL-O-RING | 1 | |
| 3649621 | CONNECTOR | 1 | |
| 3650592 | 9 CONNECTOR AS | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3649633 | CONNECTOR | 1 | |
| 3621615 | 10 BRACKET AS | 4 | |
| 3576232 | 11 PLATE AS | 2 | |
| 2815849 | 12 TEE-UNION | 1 | |
| 0L1351 | 13 BOLT (3/8-16X0.875-IN) | 1 | |
| 0S0509 | 14 BOLT (3/8-16X0.75-IN) | 1 | |
| 0S1591 | 15 BOLT (3/8-16X1.5-IN) | 2 | |
| 1749599 | 16 STUD (3/8-16-THD) | 1 | |
| 2B2695 | 17 BOLT (5/16-18X0.875-IN) | 3 | |
| 1D4541 | 18 BOLT (5/16-18X3-IN) | 1 | |
| 2H3755 | 19 BOLT (5/16-18X0.43-IN) | 6 | |
| 1W7474 | 20 STUD (3/8-16X2.25-IN) | 1 | |
| 3422134 | 21 CLIP | 3 | |
| 3453350 | 22 CLIP | 7 | |
| 9M4136 | 23 SPACER (0.438X0.75X0.5-IN THK) | 2 | |
| 2141048 | 24 SPACER (8.8X16X4-MM THK) | 1 | |
| 3118802 | 25 SPACER (10.5X19X57-MM THK) | 1 | |
| 5M2894 | 26 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 9M1974 | 27 WASHER-HARD (8.8X16X2-MM THK) | 10 | |
| 2901993 | 28 STRAP-CABLE | 6 | |
| 3177012 | 29 CLAMP-BAND | 4 | |
| 3374178 | 30 HOSE (17-CM EACH) | ||
| 3304374 | 31 SLEEVE (27-CM EACH) |
