Assembly
100%

351-8414 LINES GP-TURBOCHARGERPROVIDES A GROUP TO CREATE A PRESSURE REFERENCE CIRCUIT FROM MIXER THROUGH BALANCE VALVE SOLENOID, TO BALANACE VALVE ACTUATOR

Group No: 351-8414
Part NumberPart NameQty
36420031 TUBE AS-AIR1
31770122 CLAMP-BAND4
39721103 TUBE AS-AIR1
39722654 TUBE AS-AIR1
36420115 TUBE AS-AIR1
36420156 TUBE AS-AIR1
36496347 ELBOW AS1
1716469ELBOW1
2147566SEAL-O-RING1
36496228 CONNECTOR AS1
2147567SEAL-O-RING1
3649621CONNECTOR1
36505929 CONNECTOR AS1
2147566SEAL-O-RING1
3649633CONNECTOR1
362161510 BRACKET AS2
357623211 PLATE AS2
052057212 TEE-SWIVEL1
0L135113 BOLT (3/8-16X0.875-IN)1
0S050914 BOLT (3/8-16X0.75-IN)1
0S159115 BOLT (3/8-16X1.5-IN)2
174959916 STUD (3/8-16-THD)1
2B269517 BOLT (5/16-18X0.875-IN)2
2H375519 BOLT (5/16-18X0.43-IN)4
1D453820 BOLT (5/16-18X2.25-IN)1
342213421 CLIP3
345335022 CLIP4
9M413623 SPACER (0.438X0.75X0.5-IN THK)2
1W747424 STUD (3/8-16X2.25-IN)1
2L905625 SPACER (0.344X0.75X0.313-IN THK)1
5M289426 WASHER-HARD (10.2X18.5X2.5-MM THK)5
9M197427 WASHER-HARD (8.8X16X2-MM THK)6
290199328 STRAP-CABLE6
3E435229 WASHER-HARD (8.8X20.5X2.5-MM THK)1
3L287530 CLIP1
6W667231 SPACER (10.5X20X38-MM THK)1
337417832 HOSE (14-CM)
337417832A HOSE (17-CM)
330437433 SLEEVE (26-CM)
330437433A SLEEVE (24-CM)
