System And Components
307-2933 MOUNTING GP-AIR CLEANERFOR USE WITH 308-3424, TIER II
Group No: 307-2933
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N5991 | 1 HOSE | 2 | |
| 9N0720 | 2 ELBOW-AIR INLET | 4 | |
| 1230275 | 3 CONNECTOR-FILTER | 1 | |
| 1505030 | 4 INDICATOR-AIR FILTER CHANGE | 1 | |
| 2051627 | 5 BRACKET | 1 | |
| 2550099 | 6 BRACKET AS | 1 | |
| 2552432 | BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 10 | |
| 2545719 | 7 MANIFOLD AS | 1 | |
| 2545723 | 8 BRACKET | 1 | |
| 2545724 | 9 BRACKET | 1 | |
| 0966166 | 10 WASHER-HARD (4.5X9X1-MM THK) | 2 | |
| 4D8123 | 11 CLIP (LOOP) | 2 | |
| 2162212 | 12 CLAMP | 8 | |
| 2338484 | 13 CLAMP (BOLT SPRING) | 4 | |
| 8T0285 | 14 SCREW-MACHINE (M4X0.7X12-MM) | 2 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 20 | |
| 9X8274 | 16 BOLT-HIGH TEMPERATURE (M10X1.5X25-MM) | 20 | |
| 6V1363 | 17 HOSE (1.4-M) |
