System And Components
369-7542 LINES GP-FUEL FILTERType 2
Group No: 369-7542
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0692 | 1 CLAMP AS | 6 | |
| 1081434 | GROMMET | 1 | |
| 3522174 | 2 BRACKET AS | 1 | |
| 3621752 | 3 HOSE AS | 1 | |
| 3621753 | 4 TUBE AS-FUEL | 1 | |
| 3621754 | 5 SPACER (9.6X19X68-MM THK) | 1 | |
| 3758202 | 6 HOSE AS | 1 | |
| 3758203 | 7 HOSE AS | 1 | |
| 0304285 | 8 CONNECTOR | 1 | |
| 0L1143 | 10 BOLT (3/8-16X2.5-IN) | 4 | |
| 0L1351 | 11 BOLT (3/8-16X0.875-IN) | 1 | |
| 0S1588 | 12 BOLT (3/8-16X1.25-IN) | 2 | |
| 3537952 | 13 GROMMET | 1 | |
| 1F6296 | 14 BOLT (5/16-18X0.5-IN) | 1 | |
| 3510258 | 15 ELBOW AS | 2 | |
| 1P7625 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2385080 | 16 SEAL-O-RING | 1 | |
| 3535133 | 18 ELBOW AS | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 0307949 | ELBOW | 1 | |
| 3E4352 | 19 WASHER-HARD (8.8X20.5X2.5-MM THK) | 1 | |
| 3G8047 | 20 GROMMET | 1 | |
| 3G8054 | 21 CLIP (TAB) | 1 | |
| 3G8057 | 22 CLIP (SLOT) | 1 | |
| 5M2894 | 23 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8M9124 | 24 WASHER (10X22.5X8-MM THK) | 2 | |
| 8T1897 | 25 CLIP (SLOT) | 1 | |
| 8T1898 | 26 CLIP (TAB) | 1 | |
| 9S8752 | 27 NUT-FULL (3/8-16-THD) | 1 | |
| 9X6458 | 28 WASHER-HARD (10.2X22.5X3-MM THK) | 5 | |
| 3650578 | 29 CONNECTOR AS | 1 | |
| 2P7636 | CONNECTOR (3/4-16 STR-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 |
