System And Components
349-7009 SENSOR GP-ENGINEALSO AN ATTACHMENT
Group No: 349-7009
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E5276 | 1 ADAPTER | 1 | |
| 3S2093 | 2 STRAP-CABLE | 2 | |
| 7C1947 | 3 FILTER-ORIFICE | 1 | |
| 1255835 | 4 PLUG-FELT | 1 | |
| 2147568 | 5 SEAL-O-RING | 1 | |
| 2345012 | 6 SENSOR GP-TEMPERATURE | 1 | |
| 2345013 | 7 SENSOR GP-TEMPERATURE (INLET AIR) | 1 | |
| 2345013 | 7A SENSOR GP-TEMPERATURE (INLET AIR) | 1 | |
| 2769067 | 8 SENSOR GP-PRESSURE (ENGINE OIL)(ENGINE OIL) | 1 | |
| 2946119 | 9 SENSOR GP-PRESSURE (CRANKCASE BREATHER) | 1 | |
| 3009805 | 10 SENSOR GP-SPEED (PRIMARY, TIMING) | 1 | |
| 3009806 | 11 SENSOR GP-SPEED (SECONDARY, TIMING) | 1 | |
| 3311134 | 12 SENSOR GP-PRESSURE (ATMOSPHERIC) | 1 | |
| 3320296 | 13 SENSOR GP-PRESSURE (NRS ABSOLUTE) | 1 | |
| 3320296 | 13A SENSOR GP-PRESSURE | 1 | |
| 3353999 | 14 CONNECTOR | 1 | |
| 3398822 | 15 SENSOR AS-TEMPERATURE (NOX REDUCTION SYSTEM) | 1 | |
| 3587306 | 16 SENSOR GP-PRESSURE (NOX REDUCTION SYSTEM) | 1 | |
| 3488183 | 17 CLIP | 1 | |
| 1378101 | 18 SEAL-O-RING | 2 | |
| 2287101 | 19 SEAL-O-RING | 3 | |
| 2416170 | 20 PLUG | 3 | |
| 0S1614 | 21 BOLT (1/4-20X0.5-IN) | 1 | |
| 2H3755 | 22 BOLT (5/16-18X0.43-IN) | 2 | |
| 4P7581 | 23 CLIP (LADDER) | 1 | |
| 5J5314 | 24 BOLT (5/16-18X1.5-IN) | 2 | |
| 5P0537 | 25 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 6V4589 | 26 SEAL-O-RING | 1 | |
| 6V5839 | 27 WASHER (11X21X2.5-MM THK) | 1 | |
| 6V8801 | 28 NUT (3/8-16-THD) | 1 | |
| 2385080 | 29 SEAL-O-RING | 2 | |
| 8S0527 | 30 PLUG-CUP | 2 | |
| 8T7922 | 31 SCREW-HEX SOCKET (10-24X0.383-IN) | 1 | |
| 9M1974 | 32 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9S8005 | 33 PLUG (3/4-16-THD) | 2 |
