367-8642 SENSOR GP-ENGINES/N RAM106-UP

Group No: 367-8642

Part Number	Part Name	Qty
3E5276	1 ADAPTER	1
6J4608	2 BOLT-SOCKET HEAD (5/16-18X0.625-IN)	2
7C1947	3 FILTER-ORIFICE	1
7K1181	4 STRAP-CABLE	5
1255835	5 PLUG-FELT	1
2345012	6 SENSOR GP-TEMPERATURE (COOLANT)	1
2345013	7 SENSOR GP-TEMPERATURE (AIR INLET MANIFOLD)	2
2769067	8 SENSOR GP-PRESSURE (ENGINE OIL)	1
2946119	9 SENSOR GP-PRESSURE (CRANKCASE PRESSURE)	1
2987202	10 HARNESS AS-SENSOR	1
9X1386	SLEEVE (23-CM)
9X3401	PIN-CONNECTOR (16-GA TO 18-GA)	3
1261767	PIN-CONNECTOR (14-GA TO 16-GA)	3
1945226	TERMINAL AS (16-GA)	3
1945227	TERMINAL AS (14-GA)	3
2370227	PLUG AS-CONNECTOR (3-PIN)	1
4550705	SEAL-CONNECTOR	1
2370228	RECEPTACLE AS-CONNECTOR (3-PIN)	1
3009805	11 SENSOR GP-SPEED (PRIMARY, TIMING)	1
3009806	12 SENSOR GP-SPEED (SECONDARY, TIMING)	1
3311134	13 SENSOR GP-PRESSURE (ATMOSPHERIC)	1
3320296	14 SENSOR GP-PRESSURE (AIR INLET MANIFOLD)	1
3320296	14A SENSOR GP-PRESSURE (NRS ABSOLUTE)	1
3353999	15 CONNECTOR	1
3398822	16 SENSOR AS-TEMPERATURE (NOX REDUCTION SYSTEM)	1
2818802	RECEPTACLE AS-CONNECTOR (2-PIN)	1
3488183	17 CLIP	1
3587306	18 SENSOR GP-PRESSURE (NRS DIFFERENTIAL)	1
3678643	19 BRACKET	1
0S1614	20 BOLT (1/4-20X0.5-IN)	1
0S1617	21 BOLT (5/16-18X0.75-IN)	1
1378101	22 SEAL-O-RING	2
1751367	23 SPACER (8.8X16X10-MM THK)	1
2147568	24 SEAL-O-RING	1
2287101	25 SEAL-O-RING	3
2385080	26 SEAL-O-RING	2
2416170	27 PLUG	3
2H3755	28 BOLT (5/16-18X0.43-IN)	2
4P7581	29 CLIP (LADDER)	1
5P0537	30 WASHER-HARD (7.2X14.5X2-MM THK)	1
5S0003	31 NUT (5/16-18-THD)	1
1367227	32 SEAL-O-RING	1
6V5839	33 WASHER (11X21X2.5-MM THK)	1
6V8801	34 NUT (3/8-16-THD)	1
8S0527	35 PLUG-CUP	2
8T7922	36 SCREW-HEX SOCKET (10-24X0.383-IN)	1
9M1974	37 WASHER-HARD (8.8X16X2-MM THK)	6
9S8005	38 PLUG (3/4-16-THD)	2
