System And Components
367-8642 SENSOR GP-ENGINES/N RAM106-UP
Group No: 367-8642
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E5276 | 1 ADAPTER | 1 | |
| 6J4608 | 2 BOLT-SOCKET HEAD (5/16-18X0.625-IN) | 2 | |
| 9S8005 | 3 PLUG (3/4-16-THD) | 2 | |
| 7K1181 | 4 STRAP-CABLE | 4 | |
| 1255835 | 5 PLUG-FELT | 1 | |
| 2345012 | 6 SENSOR GP-TEMPERATURE (COOLANT) | 1 | |
| 2345013 | 7 SENSOR GP-TEMPERATURE (AIR INLET MANIFOLD) | 2 | |
| 2769067 | 8 SENSOR GP-PRESSURE (ENGINE OIL) | 1 | |
| 9M1974 | 9 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 3009805 | 11 SENSOR GP-SPEED (PRIMARY, TIMING) | 1 | |
| 3009806 | 12 SENSOR GP-SPEED (SECONDARY, TIMING) | 1 | |
| 3311134 | 13 SENSOR GP-PRESSURE (ATMOSPHERIC) | 1 | |
| 3320296 | 14 SENSOR GP-PRESSURE (AIR INLET MANIFOLD) | 1 | |
| 3320296 | 14A SENSOR GP-PRESSURE (NRS ABSOLUTE) | 1 | |
| 3353999 | 15 CONNECTOR | 1 | |
| 3398822 | 16 SENSOR AS-TEMPERATURE (NOX REDUCTION SYSTEM) | 1 | |
| 2818802 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 3659858 | 18 SENSOR GP-PRESSURE (DIFFERENTIAL)(NRS) | 1 | |
| 3715933 | 19 BRACKET | 1 | |
| 6V8801 | 20 NUT (3/8-16-THD) | 1 | |
| 0S1617 | 21 BOLT (5/16-18X0.75-IN) | 1 | |
| 6V5839 | 22 WASHER (11X21X2.5-MM THK) | 1 | |
| 1751367 | 23 SPACER (8.8X16X10-MM THK) | 1 | |
| 2147568 | 24 SEAL-O-RING | 1 | |
| 2287101 | 25 SEAL-O-RING | 3 | |
| 2385080 | 26 SEAL-O-RING | 2 | |
| 2416170 | 27 PLUG | 3 | |
| 2H3755 | 28 BOLT (5/16-18X0.43-IN) | 2 | |
| 4P7581 | 29 CLIP (LADDER) | 1 | |
| 1367227 | 30 SEAL-O-RING | 1 | |
| 5S0003 | 31 NUT (5/16-18-THD) | 1 |
