System And Components
107-0997 STARTING MOTOR GP-ELECTRICPART OF 108-5546 STARTING MOTOR GP-ELECTRIC
Group No: 107-0997
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0369823 | 1 BOLT (1/4-28X1-IN) | 13 | |
| 3L3380 | 2 BUSHING-TERMINAL | 1 | |
| 3T3418 | 3 FRAME AS-END | 1 | |
| 3T3423 | 4 CUP | 1 | |
| 9G4101 | 5 BUSHING-END | 1 | |
| 3T3424 | 6 PLUG-FELT | 1 | |
| 7M0327 | 7 WASHER-THRUST (17.4X25.4X1.6-MM THK) | 1 | |
| 7M8651 | 8 ARMATURE AS | 1 | |
| 7M0324 | 9 COIL AS-FIELD | 1 | |
| 9H3757 | 10 WASHER (0.516X1X0.094-IN THK) | 2 | |
| 7X0562 | 11 WASHER-HARD (13.5X19X0.8-MM THK) | 6 | |
| 6V8188 | 12 NUT (1/2-13-THD) | 6 | |
| 7M0326 | 13 CONNECTOR | 1 | |
| 8T4205 | 14 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 3E7769 | 15 SOLENOID AS (STARTER) | 1 | |
| 6V1322 | 16 BOLT (1/4-20X0.375-IN) | 4 | |
| 4M1831 | 17 PLUG-LEVER HOUSING | 4 | |
| 7L2894 | 18 GASKET | 4 | |
| 3F0379 | 19 SCREW-POLE SHOE (3/8-24-THD) | 12 | |
| 7M0325 | 20 INSULATOR | 1 | |
| 7F3488 | 21 SHOE-POLE | 6 | |
| 1S7446 | 22 SCREW-MACHINE (8-32X0.437-IN) | 3 | |
| 3T9524 | 23 BRUSH AS | 6 | |
| 9S2544 | 24 SCREW-HEX HEAD (8-32X11.13-MM) | 6 | |
| 3T9525 | 25 PLATE AS-BRUSH (STARTING MOTOR) | 1 | |
| 6T0371 | 26 INSULATOR | 1 | |
| 3T4711 | 27 SCREW AS (10-32X17.5-MM) | 12 | |
| 9F5599 | LOCKWASHER | 12 | |
| 7F3525 | 28 WASHER-SPECIAL (0.207X0.39X0.09-IN THK) | 6 | |
| 6T0372 | 29 PLATE | 1 | |
| 3T4709 | 30 PLATE | 3 | |
| 2L6679 | 31 PLATE-INSULATOR | 3 | |
| 3T4710 | 32 PLATE | 3 | |
| 6T0363 | 33 HOLDER AS-BRUSH | 6 | |
| 3T9494 | 34 SPRING | 1 | |
| 2D6392 | 35 SEAL-O-RING | 1 | |
| 2J8163 | 36 SEAL-O-RING | 2 | |
| 7F3491 | 37 WASHER (0.516X1X0.094-IN THK) | 2 | |
| 3R8801 | 38 CLAMP | 1 | |
| 6N3826 | 39 DRIVE AS-MOTOR | 1 | |
| 1H2629 | 40 STRIP-INSULATION | 3 | |
| 6V4155 | 41 TERMINAL AS | 1 | |
| 9M7606 | 42 PLUNGER AS | 1 | |
| 0369821 | 43 WASHER | 1 | |
| 4M1829 | 44 BOOT-RUBBER | 1 | |
| 4M1828 | 45 RETAINER-SPRING | 1 | |
| 9M7609 | 46 SPRING (SHIFT LEVER) | 1 | |
| 1H1023 | 47 SEAL-O-RING | 1 | |
| 3E7771 | 48 HOUSING AS (STARTING MOTOR) | 1 | |
| 3T3424 | 49 PLUG-FELT | 2 | |
| 3T3423 | 50 CUP | 2 | |
| 1M9968 | 51 BUSHING | 1 | |
| 2F6678 | 52 SEAL-LIP TYPE | 1 | |
| 4L2729 | 53 WASHER (0.844X1.9X0.188-IN THK) | 1 | |
| 4M1854 | 54 SHAFT-LEVER | 1 | |
| 2H3429 | 55 RING-RETAINING | 2 | |
| 4M1853 | 56 LEVER AS-SHIFT | 1 | |
| 5M3034 | 57 LOCKNUT (5/16-24-THD) | 1 | |
| 1M9971 | 58 SPACER (0.835X1.72X0.188-IN THK) | 1 | |
| 4M1827 | 59 RETAINER-SPRING | 1 | |
| 8C3089 | 60 SEAL-O-RING | 1 | |
| 7T3974 | 61 HOUSING AS-DRIVE | 1 | |
| 4M1896 | 62 BUSHING-TERMINAL | 1 | |
| 8C9660 | 63 WASHER (4.6X7.9X0.8-MM THK) | 3 | |
| 3T9494 | 64 SPRING | 6 | |
| 5J5314 | 65 BOLT (5/16-18X1.5-IN) | 5 | |
| 3N3763 | 66 KIT-TERMINAL (STARTING MOTOR) | 1 | |
| 7X3373 | 70 BOLT (5/16-18X0.88-IN) | 1 | |
| 6N3279 | 71 INSULATOR | 1 | |
| 4B2049 | 72 NUT (10-32-THD) | 2 | |
| 8T0328 | 73 WASHER-HARD (5.5X10X1-MM THK) | 10 | |
| 8F1434 | 74 LOCKWASHER | 2 | |
| 3T3434 | 75 PLUG | 6 |
